TPS61236PRWLT The Texas Instruments TPS61236PRWLT is a synchronous boost converter designed for high-efficiency power conversion. It features an adjustable output voltage and high current capability.
Mfr Part #:

TPS61236PRWLT

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TPS61236PRWLT is a synchronous boost converter designed for high-efficiency power conversion. It features an adjustable output voltage and high current capability.
✓ Total Stock: 46,440 pcs
$ Price Range: $1.15

TPS61236PRWLT Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
45,200 pcs
On Request
45200 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
1,236 pcs
On Request
1236 pcs On Request 1 On Request On Request On Request On Request On Request
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
4 pcs
On Request
4 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TPS61236PRWLT Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Efficiency
Frequency
Function
Mounting Type
Number of Outputs
Operating Temperature
Output Configuration
Output Type
Quiescent Current
Storage Temperature
Supplier Device Package
Synchronous Rectifier
Tape & Reel
Topology
Voltage
View Similar Products (0)

TPS61236PRWLT Description

Short technical summary and product information.

The TPS61236PRWLT from Texas Instruments is a high-efficiency synchronous boost converter suitable for single-cell Li-Ion and Li-polymer battery powered devices. It integrates internal power switches capable of delivering up to 3.5-A output current for 3.3-V to 5-V conversion, with efficiencies reaching up to 97%.



This device supports a programmable constant output current, aiding in power delivery control and reducing system thermal dissipation. It operates with a 1-MHz switching frequency and features soft-start, current limit, over-voltage, and thermal shutdown protections for system safety. The TPS61236PRWLT is housed in a compact 2.5 mm x 2.5 mm VQFN package, making it ideal for space-constrained applications.



Key electrical specifications include an input voltage range starting from 2.3 V, an adjustable output voltage from 2.9 V to 5.5 V, and a switch current capability of 6.5 A. The quiescent current is as low as 10 µA under light load conditions. The operating temperature range is -40°C to 125°C.



Applications for the TPS61236PRWLT include power banks, battery backup units, USB charging ports, USB Type-C implementations, battery-powered USB hubs, tablet PCs, and other portable battery-powered products.

TPS61236PRWLT Quick Information

Product Type: DC DC Switching Regulator
Canonical Name: Texas Instruments TPS61236P Synchronous Boost Converter
Subcategory: Boost Converter

TPS61236PRWLT Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TPS61236PRWLT Estimated Pricing

Qty Low High
1+ $1.15 $1.15

Estimated market price range - modelled values for guidance only, not live distributor offers.

TPS61236PRWLT Features

  • Up to 97% efficiency synchronous boost.
  • Adjustable output voltage from 2.9V to 5.5V.
  • 6.5A internal power switch current.
  • 1MHz switching frequency operation.
  • Compact 2.5mm x 2.5mm VQFN package.

TPS61236PRWLT Applications

  • Ideal for power banks and battery backup.
  • Suitable for USB charging ports.
  • Used in portable battery-powered products.
  • Supports USB Type-C applications.
  • Applicable for tablet PCs.

TPS61236PRWLT FAQs

6 frequently asked questions generated from this part’s specifications.
What is the input and output voltage range of the TPS61236PRWLT?

Input voltage is 2.3V. Output voltage is adjustable from 2.9V to 5.5V.

What package does the TPS61236PRWLT come in?

9-VQFN-HR (2.5x2.5) surface mount package.

What is the operating temperature range?

-40°C to 125°C (junction temperature).

What is the efficiency of the TPS61236PRWLT?

Up to 97% synchronous boost efficiency.

What is the switching frequency?

1 MHz.

What is the quiescent current?

10 µA under light load conditions.
