| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7,232 pcs
|
7232 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Failure Rate | |
| Function | |
| Halogen Free | |
| Lead Style | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Configuration | |
| Output Type | |
| SVHC Present | |
| Supplier Device Package | |
| Synchronous Rectifier | |
| Topology |
The TPS54810PWR from Texas Instruments is a high-performance DC DC switching regulator designed for step-down applications. It features an adjustable output voltage ranging from 0.6V to 4.5V, with a maximum output current of 7A. The device operates with an input voltage range of 2.95V to 6V and utilizes a buck topology. Its switching frequency can be adjusted between 200kHz and 2MHz, offering flexibility in design.
This regulator is housed in a 16-WFQFN exposed pad package, suitable for surface mount applications. The operating temperature range is -40°C to 85°C. The TPS54810PWR is part of the SWIFT™ series, known for its efficiency and compact footprint. It is designed for positive output configurations and includes a synchronous rectifier for improved performance.
Key specifications include a minimum input voltage of 2.95V and a maximum of 6V, with an adjustable output voltage from 0.6V up to 4.5V. The component is rated for a continuous output current of 7A. The switching frequency is configurable from 200kHz to 2MHz. The device is supplied in a 16-WQFN (3x3) package, mounted via surface mount technology. It is designed as a single output step-down regulator.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.08 | $1.08 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
0.6V to 4.5V adjustable.
2.95V to 6V.
7A.
-40°C to 85°C.
16-WFQFN Exposed Pad (16-WQFN 3x3mm).
200kHz to 2MHz.
Yes.
