The Texas Instruments TPS54610 is a high-performance, integrated synchronous buck PWM converter designed for low-input voltage, high-density distributed power systems. It operates with an input voltage range of 3V to 6V and can deliver up to 6A of continuous output current.
Key electrical specifications include an adjustable output voltage down to 0.9V with 1.0% accuracy. The device features a wide PWM frequency range, selectable between fixed 350 kHz and 550 kHz, or adjustable from 280 kHz to 700 kHz. It is also synchronizable to 700 kHz.
The TPS54610 integrates 30-mΩ MOSFET switches, contributing to high efficiency. It includes protection features such as peak current limit and thermal shutdown. The converter is available in a thermally enhanced 28-pin HTSSOP PowerPAD package, measuring 9.7mm x 6.4mm, which helps reduce board area and component count.
This device is suitable for point-of-load regulation in applications like high-performance DSPs, FPGAs, ASICs, microprocessors, and in broadband, networking, optical communications infrastructure, and portable computing.
The input voltage range is 3 V to 6 V.
The maximum output current is 6 A.
The output voltage is adjustable from 0.9 V to 4.5 V.
The operating temperature range is -40°C to 85°C.
It is available in a 28-pin HTSSOP package (9.7mm x 6.4mm).
The PWM frequency can be fixed at 350 kHz or 550 kHz, or adjusted from 280 kHz to 700 kHz, and can be synchronized to an external clock up to 700 kHz.
The adjustable output voltage has 1.0% accuracy.
