TPS2052BDR The Texas Instruments TPS2052BDR is a 2-channel power distribution switch designed for applications with heavy capacitive loads and short circuits. It features a fixed current limit and over-temperature protection.
Mfr Part #:

TPS2052BDR

Available from 9 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TPS2052BDR is a 2-channel power distribution switch designed for applications with heavy capacitive loads and short circuits. It features a fixed current limit and over-temperature protection.
✓ Total Stock: 74,966 pcs
$ Price Range: $0.47

TPS2052BDR Available from 9 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
60,267 pcs
On Request
60267 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
8,932 pcs
On Request
8932 pcs On Request 1 On Request On Request On Request On Request On Request
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
3,500 pcs
On Request
3500 pcs On Request 1 On Request On Request On Request On Request On Request
Smaxon Electronics ✓
Non-Authorised Inventory information
1,345 pcs
On Request
1345 pcs On Request 1 On Request On Request 1327+ On Request On Request
Husky International Electronic ✓
Non-Authorised Inventory information
446 pcs
On Request
446 pcs On Request 1 On Request On Request N/A On Request On Request
Risen Electronics ✓
Non-Authorised Inventory information
300 pcs
On Request
300 pcs On Request 1 On Request On Request On Request On Request On Request
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
108 pcs
On Request
108 pcs On Request 1 On Request On Request On Request On Request On Request
Speed Components Ltd ✓
Non-Authorised Inventory information
41 pcs
On Request
41 pcs On Request 1 On Request On Request 1716 On Request On Request
Bristol Electronics ✓
Non-Authorised Inventory information
27 pcs
On Request
27 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TPS2052BDR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Current
Fault Protection
Features
Input Type
Interface
Mounting Type
Number of Outputs
Operating Temperature
Operating Voltage
Output Configuration
Output Type
Ratio
Rds On (Typ)
Supplier Device Package
Switch Type
Voltage
View Similar Products (0)

TPS2052BDR Description

Short technical summary and product information.

The TPS2052BDR from Texas Instruments is a 2-channel, N-channel MOSFET power distribution switch suitable for power systems requiring multiple switches in a single package. It operates within a voltage range of 2.7V to 5.5V and provides a continuous current of 500mA per channel.



Key electrical characteristics include a typical on-resistance of 70mΩ and a fixed current limit ranging from 0.75A to 1.25A, with an accuracy of 0.25A at 1A. The device incorporates fault protection features such as over-temperature and undervoltage lockout (UVLO), along with a status flag output. The enable input is active high, controlling each switch independently.



Designed for robustness, the TPS2052BDR offers thermal and short-circuit protection. It has a typical rise time of 0.6ms, minimizing current surges during power-up. The maximum standby supply current is 1µA for dual-channel configurations. This power switch is available in an 8-SOIC surface mount package.



This component is intended for applications where heavy capacitive loads and short circuits are likely to be encountered, providing reliable power management and protection for downstream circuitry.

TPS2052BDR Quick Information

Product Type: Power Distribution Switch
Canonical Name: Texas Instruments TPS2052BDR 2-Channel Power Distribution Switch
Subcategory: Load Driver

TPS2052BDR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TPS2052BDR Estimated Pricing

Qty Low High
1+ $0.47 $0.47

Estimated market price range - modelled values for guidance only, not live distributor offers.

TPS2052BDR Features

  • Two-channel N-channel MOSFET power switch.
  • 500mA continuous current per channel.
  • 70mΩ typical on-resistance.
  • 2.7V to 5.5V operating voltage range.
  • Fixed current limit and over-temperature protection.

TPS2052BDR Applications

  • Ideal for USB power switching.
  • Suitable for heavy capacitive loads.
  • Provides short circuit protection.
  • Used in power distribution systems.

TPS2052BDR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the TPS2052BDR?

2.7V to 5.5V.

What is the package type of the TPS2052BDR?

8-SOIC surface-mount package.

What is the operating temperature range of the TPS2052BDR?

Junction temperature range is -40°C to 125°C; ambient temperature range is -40°C to 85°C.

How many output channels does the TPS2052BDR have?

2 channels.

What is the maximum continuous current per channel?

500mA per channel.

What is the typical on-resistance of the TPS2052BDR?

70mΩ.

What fault protections are included?

Current limiting (fixed), over-temperature protection, and under-voltage lockout (UVLO).
