| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
28 pcs
|
28 pcs | On Request | 1 | On Request | On Request | 08PB | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current | |
| ESD Protection | |
| Fault Protection | |
| Features | |
| Input Type | |
| Interface | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Configuration | |
| Output Type | |
| Ratio | |
| Rds On (Typ) | |
| Supplier Device Package | |
| Switch Type | |
| Voltage |
The Texas Instruments TPS2024DRG4 is a high-side N-channel MOSFET power switch designed for robust power distribution. It is suitable for applications where short circuits and heavy capacitive loads are anticipated.
Key electrical specifications include a maximum input voltage of 5.5V and a minimum of 2.7V, with a continuous current rating of 2A. The switch offers a low on-resistance (Rds On) of 33mOhm at a 5V input, minimizing voltage drop and power dissipation. It operates within a temperature range of -40°C to 125°C.
This device features fixed current limiting, over-temperature protection, and undervoltage lockout (UVLO) for enhanced system reliability. The interface is a simple On/Off control, compatible with logic-level enable inputs. The switch type is general purpose, with an output configuration as a high-side N-channel MOSFET.
The TPS2024DRG4 is available in an 8-SOIC surface-mount package, measuring 4.9mm x 6mm. It also includes ESD protection rated at 2kV Human-Body-Model and 200V Machine-Model.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.32 | $0.32 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum input voltage is 5.5V.
The typical Rds On resistance is 33mOhm.
The operating temperature range is -40°C to 125°C.
It is available in an 8-SOIC package.
It offers current limiting, over temperature protection, and undervoltage lockout (UVLO).
