The Traco Power TPP 15-115A-D is a 15W AC/DC converter designed for PCB mounting. It operates with a universal input voltage range of 85-264 VAC, making it suitable for global applications.
This open frame converter provides a stable 15VDC output at a maximum current of 1A. It boasts an efficiency of 87% and an operating temperature range of -40°C to +85°C with derating. The compact dimensions of 38.1mm x 25.4mm x 20.8mm allow for easy integration into various electronic designs.
Key features include adjustable output and universal input, making it versatile for different systems. The TPP 15-115A-D is suitable for applications in household appliances, ITE (Commercial), and medical equipment, supported by CB, CE, and cURus approval agencies.
The TPP 15-115A-D provides a 15VDC output voltage at a maximum current of 1A.
The TPP 15-115A-D has a maximum power rating of 15W.
The TPP 15-115A-D accepts a universal input voltage range of 85-264 VAC or 120-370 VDC.
The TPP 15-115A-D can operate in temperatures ranging from -40°C to +85°C, with derating.
This converter uses a 5-DIP Module package and is designed for through-hole mounting.
