| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Type | |
| Voltage | |
| Width |
This Traco Power TPP 15-103A-D is an open-frame AC/DC converter delivering 13W of power with a 3.3V output voltage and 4A current. It accepts a wide input voltage range of 85 to 264 VAC or 120 to 370 VDC, making it suitable for universal applications. Key features include adjustable output and universal input capabilities.
The converter operates within a temperature range of -40°C to 85°C with derating and boasts an efficiency of 84%. Its compact dimensions measure 38.1mm in length, 25.4mm in width, and 20.8mm in height. The through-hole mounting package (5-DIP Module) is designed for easy integration into various electronic systems.
Designed for applications such as household appliances, ITE (Commercial), and medical equipment, this converter holds approvals from CB, CE, and cURus agencies. It offers a single output and is RoHS3 compliant.
-40°C to 85°C with derating.
85-264 VAC or 120-370 VDC.
5-DIP Module, through hole mounting.
4A.
84%.
