Mfr Part #:

TPD2E001

The TPD2E001 from Texas Instruments is a 2-channel ESD protection diode designed for high-speed data interfaces like USB 2.0. It offers robust protection against electrostatic discharge events.

✓ Total Stock: 361,600 pcs

$ Price Range: $0.47

TPD2E001 Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Romaks Technologies ✓ Non-Authorised Inventory information	361,600 pcs On Request	361600 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TPD2E001 Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Texas Instruments
Number of Channels	2
Supply Current	1 nA

View Similar Products (0)

TPD2E001 Description

Short technical summary and product information.

The Texas Instruments TPD2E001 is a two-channel Transient Voltage Suppressor (TVS) based Electrostatic Discharge (ESD) protection diode array. It is rated to dissipate ESD strikes at the maximum level specified in the IEC 61000-4-2 Level 4 international standard, providing ±8-kV contact discharge and ±15-kV air-gap discharge protection.

This device features a low IO capacitance of 1.5 pF (typical) and very low leakage current of 1 nA (maximum), making it suitable for high-speed data lines. The supply voltage range is from 0.9 V to 5.5 V. The TPD2E001 is available in space-saving packages such as DRL, DRY, and WSON.

Applications for the TPD2E001 include USB 2.0, Ethernet, FireWire™, LVDS, and SVGA video connections. It is also used in devices like glucose meters and medical imaging equipment. Alternate 3, 4, and 6-channel options like TPD3E001, TPD4E001, and TPD6E001 are also available from Texas Instruments.

TPD2E001 Quick Information

Product Type: ESD Protection Diode

Canonical Name: TPD2E001 2-Channel ESD Protection Diode

Subcategory: ESD Protection Diode

TPD2E001 Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TPD2E001 Estimated Pricing

Qty	Low	High
1+	$0.47	$0.47

Estimated market price range - modelled values for guidance only, not live distributor offers.

TPD2E001 Features

2-channel ESD protection diode array
IEC 61000-4-2 Level 4 ESD protection
Low 1.5 pF typical IO capacitance
Low 1 nA maximum leakage current
0.9 V to 5.5 V supply voltage range

TPD2E001 Applications

Protects high-speed data interfaces
Ideal for USB 2.0 applications
Suitable for Ethernet connections
Used in LVDS signal lines
Applicable to SVGA video connections

TPD2E001 FAQs

7 frequently asked questions generated from this part’s specifications.

What is the ESD protection level of the TPD2E001?

IEC 61000-4-2 contact discharge ±8 kV, air discharge ±15 kV.

What is the typical input capacitance of the TPD2E001?

1.5 pF typical.

What is the breakdown voltage of the TPD2E001?

11 V minimum.

What is the clamping voltage of the TPD2E001?

16 V typical.

What is the operating supply voltage range of the TPD2E001?

0.9 V to 5.5 V.

Which high-speed interfaces does the TPD2E001 support?

Ethernet, LVDS, USB 2.0.

What package options are available for the TPD2E001?

SOT-23, SOT-5X3, USON, WSON, DRS, DZD, DRY, DRL.
