TPA3130D2DAP

The Texas Instruments TPA3130D2DAP is a Class-D audio amplifier with analog input. It operates from a 4.5 to 26V supply and offers up to 15W stereo output power.

✓ Total Stock: 45,281 pcs

$ Price Range: $1.20

TPA3130D2DAP Available from 3 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Romaks Technologies ✓ Non-Authorised Inventory information	45,200 pcs On Request	45200 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Optech Co.,Limited ✓ Non-Authorised Inventory information	56 pcs On Request	56 pcs	On Request	1	On Request	On Request	12+	On Request	On Request
Seba Components ✓ Non-Authorised Inventory information	25 pcs On Request	25 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TPA3130D2DAP Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Texas Instruments
Lead Spacing	0.65 mm
Operating Temperature	-40 to 85 °C
Output Power	15 W
Storage Temperature	°C ~ °C
Supply Voltage	4.5 to 26 V
Tape & Reel	No

View Similar Products (0)

TPA3130D2DAP Description

Short technical summary and product information.

The Texas Instruments TPA3130D2DAP is an analog input Class-D audio amplifier designed for home audio, speaker, TV, and soundbar applications. It supports a wide supply voltage range from 4.5V to 26V, providing flexibility for various power requirements.

This amplifier delivers up to 15W of stereo output power into an 8-ohm load at 15V. It features efficient Class-D operation with over 90% power efficiency and low idle loss, which helps in reducing the need for large heat sinks. The device operates with a switching frequency of up to 1.2 MHz, incorporating advanced modulation schemes and AM avoidance.

Packaged in a 32-pin HTSSOP (DAP), the TPA3130D2DAP is suitable for surface-mount applications. It operates within an ambient temperature range of -40°C to 85°C. The amplifier includes integrated self-protection circuits for overvoltage, undervoltage, overtemperature, DC-detect, and short circuits with error reporting.

TPA3130D2DAP Quick Information

Product Type: Class-D Audio Amplifier

Canonical Name: TPA3130D2DAP Class-D Audio Amplifier

Subcategory: Class-D Amplifier

TPA3130D2DAP Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TPA3130D2DAP Estimated Pricing

Qty	Low	High
1+	$1.20	$1.20

Estimated market price range - modelled values for guidance only, not live distributor offers.

TPA3130D2DAP Features

15W stereo output into 8-ohm load
Wide 4.5V to 26V supply voltage range
Over 90% power efficiency
Up to 1.2 MHz switching frequency
32-pin HTSSOP (DAP) package

TPA3130D2DAP Applications

Home audio systems
Speaker and soundbar applications
TV audio amplification
Portable audio devices

TPA3130D2DAP FAQs

6 frequently asked questions generated from this part’s specifications.

What is the output power of the TPA3130D2DAP?

The TPA3130D2DAP provides 15W stereo output into an 8-ohm load at 15V.

What is the operating supply voltage range for the TPA3130D2DAP?

The TPA3130D2DAP operates from a supply voltage range of 4.5V to 26V.

What is the operating temperature range of the TPA3130D2DAP?

The operating temperature range for the TPA3130D2DAP is -40°C to 85°C.

What package type is the TPA3130D2DAP supplied in?

The TPA3130D2DAP is supplied in a 32-pin HTSSOP (DAP) package.

What is the RoHS status of the TPA3130D2DAP?

The TPA3130D2DAP is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the TPA3130D2DAP?

The Moisture Sensitivity Level (MSL) for the TPA3130D2DAP is Level 3.
