| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,600 pcs
|
1600 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Number of Positions |
The Lumex Opto/Components Inc. TP-105-01-09 is part of the TP-105 series test points, providing a functionally superior alternative for board-level troubleshooting compared to standard header posts. This test point features a loop profile designed for positive test probe retention. It is available in any combination of positions from one to forty, with a center spacing of 0.100" and fits into a 0.035" diameter hole.
The board profile of the TP-105 series is substantially lower than that of traditional headers, allowing for re-fits without printed circuit board layout redesign costs. This significantly reduces test point height and improves overall function. Visibility and identification are enhanced by the availability of ten standard colors, representing industry color codes. The TP-105 can be purchased pre-cut to any specified number of positions. Its mounting leg design ensures positive retention in the circuit board during soldering operations.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.07 | $0.07 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The center spacing for the TP-105-01-09 test point is 0.100 inches.
The TP-105-01-09 test point fits in a 0.035 inch diameter hole.
The TP-105-01-09 test point is available in any combination of positions from one to forty.
The TP-105 series offers ten standard colors for visibility and identification.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is Level 1.
The REACH status is REACH Unaffected.
