Mfr Part #:

TOP247YN

Mfr Name: POWER

The POWER TOP247YN is an Off-Line Converter IC integrating a high-voltage power MOSFET and PWM control. It features a 132 kHz switching frequency and various protection functions.

✓ Total Stock: 212 pcs

$ Price Range: $9.79

TOP247YN Available from 4 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Optech Co.,Limited ✓ Non-Authorised Inventory information	100 pcs On Request	100 pcs	On Request	1	On Request	On Request	10+	On Request	On Request
Smaxon Electronics ✓ Non-Authorised Inventory information	100 pcs On Request	100 pcs	On Request	1	On Request	On Request	1710+	On Request	On Request
Fe Components ✓ Non-Authorised Inventory information	10 pcs On Request	10 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
RAD ✓ Non-Authorised Inventory information	2 pcs On Request	2 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TOP247YN Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	POWER

View Similar Products (0)

TOP247YN Description

Short technical summary and product information.

The TOP247YN from POWER is an Off-Line Converter that integrates a high-voltage power MOSFET, PWM control, and fault protection onto a single CMOS chip. This design reduces system cost and improves performance and energy efficiency.

Key features include an extended power range for higher power applications and no heatsink requirement up to 34 W using P/G packages. It offers fully integrated soft-start for minimum stress and overshoot, and an externally programmable accurate current limit. The device provides line sensing for OV/UV detection and line feed-forward with DCMAX reduction.

All package types include transparent features like 132 kHz switching frequency (automatically reduced at light load), frequency jittering for lower EMI, wider DCMAX, and hysteretic thermal shutdown for automatic fault recovery. A half frequency option is available in Y/R/F packages for video applications. The TOP247YN regulates to zero load without requiring a dummy load, simplifying design and optimizing system cost.

This component is suitable for various power supply designs where efficiency, cost-effectiveness, and integrated protection features are critical. Its design flexibility and performance enhancements make it a valuable choice for engineers.

TOP247YN Quick Information

Product Type: Off-Line Converter

Series: TOPSwitch-GX

Canonical Name: TOP247YN Off-Line Converter

Subcategory: Off-Line Converter

TOP247YN Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TOP247YN Estimated Pricing

Qty	Low	High
1+	$9.79	$9.79

Estimated market price range - modelled values for guidance only, not live distributor offers.

TOP247YN Features

Integrated high-voltage power MOSFET and PWM control.
132 kHz switching frequency, reducible at light load.
Externally programmable accurate current limit.
Hysteretic thermal shutdown for fault recovery.
No heatsink required up to 34W (P/G packages).

TOP247YN Applications

Off-line power supply designs.
High power applications.
Video applications (Y/R/F packages).
Designs requiring low EMI.
Cost-sensitive power solutions.

TOP247YN FAQs

6 frequently asked questions generated from this part’s specifications.

What is the switching frequency of the TOP247YN?

The switching frequency is 132 kHz, which is automatically reduced at light load. A half frequency option of 66 kHz is available in Y/R/F packages for video applications.

Does the TOP247YN require a heatsink?

No heatsink is required for the TOP247YN up to 34 W when using P/G packages.

What protection features are included in the TOP247YN?

The TOP247YN includes line under-voltage (UV) detection, line overvoltage (OV) shutdown, and hysteretic thermal shutdown for automatic fault recovery.

Can the current limit be adjusted on the TOP247YN?

Yes, the TOP247YN features an externally programmable accurate current limit.

What is the RoHS status of the TOP247YN?

The RoHS status is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the TOP247YN?

The Moisture Sensitivity Level (MSL) is 1 Unlimited.
