TNPW06034K22DEEA The Vishay Dale TNPW06034K22DEEA is a surface mount chip resistor with a resistance of 4.22 kOhms and a tolerance of ±0.5%. It has a power rating of 0.1W.
Mfr Part #:

TNPW06034K22DEEA

Available from 1 distributors
Mfr Name: Vishay
Vishay
The Vishay Dale TNPW06034K22DEEA is a surface mount chip resistor with a resistance of 4.22 kOhms and a tolerance of ±0.5%. It has a power rating of 0.1W.
✓ Total Stock: 4,785 pcs
$ Price Range: $0.02

TNPW06034K22DEEA Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
4,785 pcs
On Request
4785 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TNPW06034K22DEEA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Composition
Features
Height
Length
Number of Terminations
Operating Temperature
Power (Watts)
Ratings
Resistance
Supplier Device Package
Tape & Reel
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

TNPW06034K22DEEA Description

Short technical summary and product information.

The Vishay Dale TNPW06034K22DEEA is a surface mount chip resistor designed for various electronic applications. It features a resistance value of 4.22 kOhms with a tight tolerance of ±0.5%, ensuring precise circuit performance.



This resistor has a power rating of 0.1W (1/10W) and is constructed using thin film technology. It operates within a temperature range of -55°C to 155°C, with a temperature coefficient of ±25ppm/°C. The component is housed in a compact 0603 (1608 Metric) package.



Key features include its anti-sulfur properties, AEC-Q200 automotive qualification, and moisture resistance, making it suitable for demanding environments. The component has 2 terminations and is supplied in tape and reel packaging for automated assembly processes.

TNPW06034K22DEEA Quick Information

Product Type: Chip Resistor - Surface Mount
Series: TNPW e3
Canonical Name: Vishay Dale TNPW06034K22DEEA Chip Resistor - Surface Mount 4.22 kOhms ±0.5% 0.1W
Subcategory: Chip Resistor - Surface Mount

TNPW06034K22DEEA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TNPW06034K22DEEA Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

TNPW06034K22DEEA Features

  • 4.22 kOhms resistance with ±0.5% tolerance.
  • 0.1W power rating in a 0603 package.
  • AEC-Q200 automotive qualified.
  • Anti-sulfur and moisture resistant.
  • Thin film composition for stability.

TNPW06034K22DEEA Applications

  • Suitable for automotive applications.
  • Ideal for general purpose circuits.
  • Used in signal processing circuits.
  • Designed for high reliability needs.

TNPW06034K22DEEA FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the TNPW06034K22DEEA?

The resistance value is 4.22 kOhms.

What is the tolerance of the TNPW06034K22DEEA resistor?

The tolerance is ±0.5%.

What is the power rating of the TNPW06034K22DEEA?

The power rating is 0.1W.

What is the operating temperature range for this resistor?

The operating temperature range is -55°C to 155°C.

What package size is the TNPW06034K22DEEA available in?

It is available in the 0603 (1608 Metric) package size.

Does this resistor meet automotive standards?

Yes, it is AEC-Q200 qualified and features anti-sulfur properties.
