| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Composition | |
| Features | |
| Height | |
| Length | |
| Number of Terminations | |
| Operating Temperature | |
| Power (Watts) | |
| Ratings | |
| Resistance | |
| Supplier Device Package | |
| Tape & Reel | |
| Temperature Coefficient | |
| Tolerance | |
| Width |
This Vishay Dale TNPW0603301KBEEA is a thin film chip resistor designed for surface mount applications. It offers a precise resistance value of 301 kOhms with a tight tolerance of ±0.1%, making it suitable for demanding electronic circuits.
The resistor has a power rating of 0.1W and operates within a temperature range of -55°C to 155°C. Key features include its anti-sulfur, moisture-resistant properties, and AEC-Q200 automotive qualification, ensuring reliability in harsh environments.
Packaged in a standard 0603 (1608 Metric) case, this component is ideal for automated assembly processes. Its dimensions are 1.60mm in length, 0.85mm in width, and 0.55mm in height, with 2 terminations.
The TNPW e3 series resistor is designed for applications requiring high stability and performance. Its thin film composition contributes to its accuracy and reliability over time and varying conditions.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.02 | $0.02 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The resistance value is 301 kOhms.
The tolerance is ±0.1%.
The power rating is 0.1W.
The temperature coefficient is ±25ppm/°C.
The operating temperature range is -55°C to 155°C.
It is supplied in a 0603 (1608 Metric) package.
Yes, it is AEC-Q200 qualified.
