TNPW0603180RBEEA The Vishay Dale TNPW0603180RBEEA is a surface mount chip resistor with a resistance of 180 Ohms and a tolerance of ±0.1%. It features Anti-Sulfur and Automotive AEC-Q200 compliance.
Mfr Part #:

TNPW0603180RBEEA

Available from 1 distributors
Mfr Name: Vishay
Vishay
The Vishay Dale TNPW0603180RBEEA is a surface mount chip resistor with a resistance of 180 Ohms and a tolerance of ±0.1%. It features Anti-Sulfur and Automotive AEC-Q200 compliance.
✓ Total Stock: 51 pcs
$ Price Range: $0.02

TNPW0603180RBEEA Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
51 pcs
On Request
51 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TNPW0603180RBEEA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Composition
Features
Height
Length
Number of Terminations
Operating Temperature
Power (Watts)
Ratings
Resistance
Supplier Device Package
Tape & Reel
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

TNPW0603180RBEEA Description

Short technical summary and product information.

The Vishay Dale TNPW0603180RBEEA is a thin film chip resistor designed for surface mount applications. It offers a resistance value of 180 Ohms with a tight tolerance of ±0.1% and a power rating of 0.21W. The operating temperature range is -55°C to 155°C, with a temperature coefficient of ±25ppm/°C.



This component is built to withstand harsh environments, featuring Anti-Sulfur, Automotive AEC-Q200, and Moisture Resistant characteristics. It comes in a compact 0603 (1608 Metric) package, measuring 1.60mm in length and 0.85mm in width, with a height of 0.55mm. The package type is Tape & Reel.



Its robust design and automotive qualification make it suitable for demanding applications where reliability is critical. The thin film composition ensures stable performance across its operating conditions.

TNPW0603180RBEEA Quick Information

Product Type: Chip Resistor - Surface Mount
Series: TNPW e3
Canonical Name: Vishay Dale TNPW0603180RBEEA Chip Resistor - Surface Mount
Subcategory: Surface Mount

TNPW0603180RBEEA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TNPW0603180RBEEA Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

TNPW0603180RBEEA Features

  • 180 Ohm resistance with ±0.1% tolerance.
  • 0.21W power rating in a 0603 package.
  • Automotive AEC-Q200 qualified.
  • Anti-Sulfur and Moisture Resistant features.
  • Wide operating temperature range.

TNPW0603180RBEEA Applications

  • Suitable for automotive applications.
  • Ideal for harsh environmental conditions.
  • Used in circuits requiring high precision.
  • Surface mount assembly compatibility.

TNPW0603180RBEEA FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the TNPW0603180RBEEA?

The resistance value is 180 Ohms.

What is the tolerance of the TNPW0603180RBEEA resistor?

The tolerance is ±0.1%.

What is the power rating of the TNPW0603180RBEEA?

The power rating is 0.21W.

What is the operating temperature range for this chip resistor?

The operating temperature range is -55°C to 155°C.

What package size is the TNPW0603180RBEEA available in?

It is available in the 0603 (1608 Metric) package size.

Does this resistor meet automotive standards?

Yes, it is rated AEC-Q200 and features Anti-Sulfur and Moisture Resistant properties.
