TNPW0603100KFHEA The Vishay Dale TNPW0603100KFHEA is a surface mount chip resistor with 100 kΩ resistance and ±1% tolerance. It is rated for 0.1W and features AEC-Q200 compliance.
Mfr Part #:

TNPW0603100KFHEA

Available from 2 distributors
Mfr Name: Vishay
Vishay
The Vishay Dale TNPW0603100KFHEA is a surface mount chip resistor with 100 kΩ resistance and ±1% tolerance. It is rated for 0.1W and features AEC-Q200 compliance.
✓ Total Stock: 9,940 pcs
$ Price Range: $0.02

TNPW0603100KFHEA Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Braun Electronic Components ✓
Non-Authorised Inventory information
4,970 pcs
On Request
4970 pcs On Request 1 On Request On Request On Request On Request On Request
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
4,970 pcs
On Request
4970 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TNPW0603100KFHEA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Composition
Features
Height
Length
Number of Terminations
Operating Temperature
Power (Watts)
Ratings
Resistance
Supplier Device Package
Tape & Reel
Temperature Coefficient
Tolerance
Width
View Similar Products (0)

TNPW0603100KFHEA Description

Short technical summary and product information.

The Vishay Dale TNPW0603100KFHEA is a surface mount chip resistor designed for various electronic applications. It offers a resistance value of 100 kΩ with a tight tolerance of ±1%, ensuring precise circuit performance.



This resistor has a power rating of 0.1W (1/10W) and operates within a temperature range of -55°C to 155°C. Its thin film composition contributes to its reliability. The component is built to withstand demanding conditions, featuring anti-sulfur, automotive AEC-Q200, and moisture-resistant properties.



The TNPW0603100KFHEA comes in a compact 0603 (1608 Metric) package, making it suitable for space-constrained designs. Its dimensions are approximately 1.55mm in length and 0.85mm in width, with a height of 0.55mm. The surface mount design facilitates automated assembly processes.



Key specifications include a temperature coefficient of ±50ppm/°C and two terminations. This component is suitable for applications requiring high reliability and performance in harsh environments, such as automotive systems.

TNPW0603100KFHEA Quick Information

Product Type: Chip Resistor - Surface Mount
Series: TNPW e3
Canonical Name: Vishay Dale TNPW0603100KFHEA Chip Resistor - Surface Mount 100 kΩ ±1% 0.1W
Subcategory: Surface Mount

TNPW0603100KFHEA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TNPW0603100KFHEA Estimated Pricing

Qty Low High
1+ $0.02 $0.02

Estimated market price range - modelled values for guidance only, not live distributor offers.

TNPW0603100KFHEA Features

  • 100 kΩ resistance with ±1% tolerance.
  • 0.1W power rating suitable for general use.
  • AEC-Q200 qualified for automotive applications.
  • Anti-sulfur and moisture-resistant construction.
  • Compact 0603 surface mount package.

TNPW0603100KFHEA Applications

  • Ideal for automotive electronic systems.
  • Suitable for high-reliability circuits.
  • Used in circuits requiring precise resistance.
  • Applicable in moisture-prone environments.

TNPW0603100KFHEA FAQs

6 frequently asked questions generated from this part’s specifications.
What is the resistance value of the TNPW0603100KFHEA resistor?

The TNPW0603100KFHEA resistor has a resistance value of 100 kΩ.

What is the tolerance of the TNPW0603100KFHEA resistor?

The tolerance of the TNPW0603100KFHEA resistor is ±1%.

What is the power rating of the TNPW0603100KFHEA resistor?

The power rating of the TNPW0603100KFHEA resistor is 0.1W (1/10W).

What is the operating temperature range for the TNPW0603100KFHEA resistor?

The operating temperature range for the TNPW0603100KFHEA resistor is -55°C to 155°C.

What package size is the TNPW0603100KFHEA resistor available in?

The TNPW0603100KFHEA resistor is available in the 0603 (1608 Metric) package size.

Does the TNPW0603100KFHEA resistor meet automotive standards?

Yes, the TNPW0603100KFHEA resistor is rated AEC-Q200 and features automotive suitability.
