The Traco Power TMW 36-124P is an enclosed AC/DC power supply designed for various applications including medical, ITE, and household appliances. It features a wide input voltage range of 85~264 VAC and delivers a stable 24 VDC output at a maximum current of 1.5A, providing a total power of 36W.
This power supply operates efficiently with an 88% efficiency rating and has a single output. It is designed for surface mount applications with a 4-DIP Module package. The operating temperature range is -20°C to 80°C, with derating considered. Safety certifications include CE, cURus, EAC, and UKCA, with specific compliance for medical applications like IEC/EN 60601-1 and ANSI/AAMI ES 60601-1, and suitability for BF applications with 2xMOPP.
Key specifications include dimensions of 53.0mm x 51.0mm x 34.0mm. It adheres to industrial standards such as 60335-1, 60601-1, and 62368-1. The RoHS status is RoHS3 Compliant, and the Moisture Sensitivity Level is 1 Unlimited.
The TMW 36-124P has an output voltage of 24 VDC.
The maximum output current for the TMW 36-124P is 1.5 A.
The TMW 36-124P has a power rating of 36 W.
The operating temperature range is -20°C to 80°C (With Derating).
The TMW 36-124P is supplied in a 4-DIP Module package for surface mounting.
Yes, it meets IEC/EN 60601-1 and ANSI/AAMI ES 60601-1 standards and is suitable for BF applications with 2xMOPP.
