Mfr Part #:

TMS320F28035PNQ

The Texas Instruments TMS320F28035PNQ is a 32-bit microcontroller featuring a 60 MHz clock speed, 128 KB of flash memory, and 20 KB of RAM. It is rated for automotive applications.

✓ Total Stock: 35,602 pcs

$ Price Range: $10.38

TMS320F28035PNQ Available from 4 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Optech Co.,Limited ✓ Non-Authorised Inventory information	27,524 pcs On Request	27524 pcs	On Request	1	On Request	On Request	1811	On Request	On Request
Romaks Technologies ✓ Non-Authorised Inventory information	6,746 pcs On Request	6746 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
Xingangxin ✓ Non-Authorised Inventory information	1,321 pcs On Request	1321 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request
PROSOFT ELECTRONICS ✓ Non-Authorised Inventory information	11 pcs On Request	11 pcs	On Request	1	On Request	On Request	18+	On Request	On Request

TMS320F28035PNQ Description

Short technical summary and product information.

The Texas Instruments TMS320F28035PNQ is an automotive-grade 32-bit microcontroller from the C2000 family. It operates at a frequency of 60 MHz, providing a processing power of 120 MIPS. The device includes 128 KB of flash memory for program storage and 20 KB of RAM for data.

Key features include a 12-bit SAR ADC with up to 16 channels, multiple PWM channels (8, 12, or 14), and various communication interfaces such as CAN, I2C, SPI, and UART. It also incorporates a Control Law Accelerator (CLA) for 32-bit floating-point math operations, executing code independently of the main CPU.

The microcontroller supports a wide operating temperature range of -40 to 125 °C and operates on a single 3.3V supply. It is available in TQFP and LQFP packages.

This MCU is suitable for applications requiring real-time control and processing, particularly in automotive systems.

TMS320F28035PNQ Quick Information

Product Type: Microcontroller

Series: TMS320F2803x

Canonical Name: Texas Instruments TMS320F28035-Q1 Automotive 32-bit MCU

Subcategory: Automotive MCUs

TMS320F28035PNQ Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TMS320F28035PNQ Estimated Pricing

Qty	Low	High
1+	$10.38	$10.38

Estimated market price range - modelled values for guidance only, not live distributor offers.

TMS320F28035PNQ Features

60 MHz, 32-bit C2000 microcontroller.
128 KB flash and 20 KB RAM.
12-bit SAR ADC with up to 16 channels.
Control Law Accelerator for floating-point math.
Automotive temperature range (-40 to 125 °C).

TMS320F28035PNQ Applications

Automotive motor control and power conversion.
Industrial drives and servo control.
Real-time control with fast interrupt response.
Systems requiring CAN, I2C, SPI, UART communication.
Battery management and power supply control.

TMS320F28035PNQ FAQs

7 frequently asked questions generated from this part’s specifications.

What is the supply voltage of the TMS320F28035PNQ?

3.3 V single supply.

What package options are available for the TMS320F28035PNQ?

TQFP and LQFP packages with dimensions of 144 mm² (12×12 mm) and 196 mm² (14×14 mm).

What is the operating temperature range of the TMS320F28035PNQ?

-40 to 125 °C.

What CPU core does the TMS320F28035PNQ use?

32-bit TMS320C28x CPU core.

How much Flash memory does the TMS320F28035PNQ have?

128 kB.

Does the TMS320F28035PNQ have a CAN interface?

Yes, it has one CAN module.

Does the TMS320F28035PNQ support FreeRTOS?

Yes, the operating system is FreeRTOS.

Category	New Products
Manufacturer Name	Texas Instruments
Frequency	60 MHz
Operating System	FreeRTOS
Operating Temperature Range	-40 to 125 °C
SVHC Present	Not Present
Supply Voltage	3.3 V
USB	No
Watchdog Timer	Yes
