| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
16,436 pcs
|
16436 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Frequency | |
| Operating System | |
| Operating Temperature Range | |
| SVHC Present | |
| Supply Voltage | |
| USB | |
| Watchdog Timer |
The Texas Instruments TMS320F28027 is a high-performance 32-bit microcontroller from the C2000 family, operating at a frequency of 60 MHz. It features 64 KB of flash memory for code storage and 12 KB of SARAM for data. This MCU includes a 12-bit SAR ADC with up to 13 channels, 8 PWM channels, and various communication interfaces including I2C, SPI, and UART.
Designed for efficiency and cost-effectiveness, the TMS320F28027 supports multiple operating systems like BareMetal, FreeRTOS, and SafeRTOS. It is available in compact packages such as 38-pin TSSOP and 48-pin LQFP, making it suitable for space-constrained applications. The device operates within a temperature range of -40°C to 125°C and supports a single 3.3V supply.
Key features include a watchdog timer, single-zone code security, and integrated power-on and brown-out resets. The microcontroller also boasts fast interrupt response, a Harvard bus architecture, and code efficiency for C/C++ and Assembly programming. Its capabilities make it well-suited for real-time control and automation tasks.
| Qty | Low | High |
|---|---|---|
| 1+ | $5.52 | $5.52 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The TMS320F28027 operates from a single 3.3 V supply.
The TMS320F28027 is available in TSSOP (DA) and LQFP (PT) packages.
The operating temperature range is -40°C to 125°C.
The CPU is a 32-bit C28 core.
It has 64 KB of Flash memory.
The TMS320F28027 supports I2C, SPI, and UART interfaces.
It has 22 GPIOs.
