TMS-110-02-G-D 20 position, 2 row, 1.27mm pitch through hole header with gold plated phosphor bronze contacts. Unshrouded, push-pull fastening.
Mfr Part #:

TMS-110-02-G-D

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
20 position, 2 row, 1.27mm pitch through hole header with gold plated phosphor bronze contacts. Unshrouded, push-pull fastening.
✓ Total Stock: 48 pcs
$ Price Range: $1.46 - $2.47

TMS-110-02-G-D Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
MW.FEP S.p.A. ✓
Non-Authorised Inventory information
48 pcs
On Request
48 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TMS-110-02-G-D Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Style
Material Flammability Rating
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TMS-110-02-G-D Description

Short technical summary and product information.

The TMS-110-02-G-D is a 20-position, 2-row unshrouded header from Samtec's TMS series. It features a 1.27mm pitch and is designed for board-to-board applications.



Contacts are made of phosphor bronze with 10µ" gold plating, rated for 5A per contact. The insulator is black liquid crystal polymer with UL94 V-0 flammability rating.



This through-hole header has a push-pull fastening type and operates from -55°C to +125°C. It mates with Samtec SMS, SLM, and RSM series.

TMS-110-02-G-D Quick Information

Product Type: Header, Male Pins
Series: TMS
Canonical Name: Samtec TMS-110-02-G-D 20 Position 1.27mm Pitch Through Hole Header
Subcategory: Male Pins

TMS-110-02-G-D Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

TMS-110-02-G-D Estimated Pricing

Qty Low High
1+ $2.47 $2.47
25+ $2.46 $2.46
46+ $2.29 $2.29
92+ $1.89 $1.89
1,012+ $1.70 $1.70
2,530+ $1.55 $1.55
5,014+ $1.46 $1.46

Estimated market price range - modelled values for guidance only, not live distributor offers.

TMS-110-02-G-D Features

  • 20 positions in 2 rows.
  • 1.27mm pitch for compact designs.
  • Gold plated phosphor bronze contacts.
  • Rated for 5A per contact.
  • Through hole mounting with solder termination.

TMS-110-02-G-D Applications

  • Used in board-to-board interconnects.
  • Suitable for high-density packaging.
  • Ideal for industrial control systems.
  • Common in test and measurement equipment.

TMS-110-02-G-D FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

20 positions, all loaded.

What is the pitch?

1.27mm (0.050").

What is the current rating?

5A per contact.

What is the mounting type?

Through hole.

What is the operating temperature range?

-55°C to +125°C.

What is the contact finish?

Gold, 10.0µin (0.25µm) on contact area.

What is the insulation material?

Black Liquid Crystal Polymer (LCP) with UL94 V-0 rating.
