The Traco Power TMP 10112 is an AC/DC power module designed for various industrial and commercial applications. It offers a compact, low-profile plastic casing that is fully encapsulated, making it suitable for polluted and dusty environments.
This module features a universal input voltage range of 85-264 VAC, accommodating global power standards. It delivers a stable 12V DC output at 833mA, providing up to 10W of power with an efficiency of 76%. The TMP 10112 includes essential protections such as over-temperature, short circuit, and overload protection, ensuring reliable operation.
Designed for easy integration, the TMP 10112 is available in a 5-DIP module package suitable for through-hole mounting. Its dimensions are 64.0mm x 45.0mm x 19.2mm. The operating temperature range is -25°C to 50°C, and it holds certifications including CB, CE, cULus, and cURus, qualifying it for worldwide markets.
With its robust design and compliance with international safety standards like IEC/EN/UL 62368-1, the TMP 10112 is a cost-effective solution for space-critical applications in commercial and industrial electronic equipment.
Input voltage is 85-264 VAC (120-370 VDC also accepted), and output voltage is 12 VDC.
It provides 833 mA at 12 VDC, which equals 10 W output power.
-25°C to 50°C.
It uses a 5-DIP module package with through-hole mounting.
Short-circuit, overload, and over-temperature protection.
CB, CE, cULus, and cURus.
47-440 Hz.
