TMM-116-01-L-D-RA Samtec TMM-116-01-L-D-RA is a 2.00mm pitch, 32-position, 2-row, right angle, unshrouded header. It features tin-plated phosphor bronze contacts and a black LCP insulator.
Mfr Part #:

TMM-116-01-L-D-RA

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
Samtec TMM-116-01-L-D-RA is a 2.00mm pitch, 32-position, 2-row, right angle, unshrouded header. It features tin-plated phosphor bronze contacts and a black LCP insulator.
✓ Total Stock: 76 pcs
$ Price Range: $1.67 - $3.07

TMM-116-01-L-D-RA Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Speed Components Ltd ✓
Non-Authorised Inventory information
76 pcs
On Request
76 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TMM-116-01-L-D-RA Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Spacing
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Pitch
Row Spacing
Shrouding
Style
Tape & Reel
Termination
Termination Style
Voltage Rating
View Similar Products (0)

TMM-116-01-L-D-RA Description

Short technical summary and product information.

The TMM-116-01-L-D-RA is a 2.00mm pitch, 32-position, 2-row, right angle, unshrouded header from Samtec's TMM series. It features phosphor bronze contacts with tin plating (10µin) and a black Liquid Crystal Polymer (LCP) insulator. The header is designed for through-hole soldering and offers a push-pull fastening type.



This header is rated for 3.2A per contact and 281 VAC when mated with SQW series sockets (250 VAC with SQT series). It operates over a temperature range of -55°C to +125°C. The unshrouded design allows for flexible board-to-board or cable-to-board connections.



The right angle orientation enables low-profile mounting, making it suitable for space-constrained applications. The part number indicates a -01 lead style, -L plating (10µ" gold on post, matte tin on tail), double row, and right angle option.

TMM-116-01-L-D-RA Quick Information

Product Type: Header, Male Pins
Series: TMM
Canonical Name: Samtec TMM-116-01-L-D-RA 2.00mm Pitch, 32-Position, 2-Row, Right Angle, Unshrouded Header
Subcategory: Unshrouded Right Angle Header

TMM-116-01-L-D-RA Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Lead-Free Solderable: Yes

TMM-116-01-L-D-RA Estimated Pricing

Qty Low High
1+ $3.07 $3.07
25+ $2.87 $2.87
50+ $2.79 $2.79
100+ $2.70 $2.70
500+ $2.32 $2.32
1,000+ $2.08 $2.08
2,500+ $1.87 $1.87
5,000+ $1.67 $1.67

Estimated market price range - modelled values for guidance only, not live distributor offers.

TMM-116-01-L-D-RA Features

  • 2.00mm pitch for compact designs.
  • 32 positions in 2 rows.
  • Right angle through-hole mounting.
  • Tin-plated phosphor bronze contacts.
  • Unshrouded for versatile mating.

TMM-116-01-L-D-RA Applications

  • Board-to-board interconnections.
  • Cable-to-board connections.
  • Low-profile right angle applications.
  • Industrial control systems.
  • Data communication equipment.

TMM-116-01-L-D-RA FAQs

7 frequently asked questions generated from this part’s specifications.
What is the pitch of the TMM-116-01-L-D-RA?

The pitch is 2.00mm (0.079 inches).

How many positions does the TMM-116-01-L-D-RA have?

It has 32 positions arranged in 2 rows.

What is the current rating of the TMM-116-01-L-D-RA?

The current rating is 3.2A per contact.

What is the voltage rating of the TMM-116-01-L-D-RA?

The voltage rating is 281 VAC when mated with SQW series sockets, and 250 VAC when mated with SQT series sockets.

What is the mounting type of the TMM-116-01-L-D-RA?

The mounting type is through hole, right angle.

What is the contact finish on the TMM-116-01-L-D-RA?

The contact finish is tin with a thickness of 10.0µin (0.25µm).

Is the TMM-116-01-L-D-RA RoHS compliant?

Yes, it is listed as RoHS3 compliant, but this status is unverified.
