TMM-105-01-L-S The TMM-105-01-L-S is a 5-position single row through-hole header from Samtec's TMM series. It features a 2.00mm pitch, gold flash on post and matte tin on tail contacts, and is rated for 3.2A per contact.
Mfr Part #:

TMM-105-01-L-S

Available from 1 distributors
Mfr Name: Samtec Inc.
Samtec Inc.
The TMM-105-01-L-S is a 5-position single row through-hole header from Samtec's TMM series. It features a 2.00mm pitch, gold flash on post and matte tin on tail contacts, and is rated for 3.2A per contact.
✓ Total Stock: 55 pcs
$ Price Range: $0.17 - $0.72

TMM-105-01-L-S Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Bristol Electronics ✓
Non-Authorised Inventory information
55 pcs
On Request
55 pcs On Request 1 On Request On Request 2026-02-25 06:16:38 On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TMM-105-01-L-S Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Connector Type
Contact Finish
Contact Finish Thickness
Contact Length
Contact Material
Contact Shape
Contact Type
Current Rating (Amps)
Fastening Type
Insulation Color
Insulation Height
Insulation Material
Lead Style
Mounting Type
Number of Positions
Number of Positions Loaded
Number of Rows
Operating Temperature
Overall Contact Length
Pitch
Shrouding
Style
Tape & Reel
Termination
View Similar Products (0)

TMM-105-01-L-S Description

Short technical summary and product information.

The Samtec TMM-105-01-L-S is a 5-position single row through-hole header from the TMM series, designed for board-to-board or cable applications. It features a 2.00mm pitch, making it suitable for compact designs where space is at a premium. The header uses phosphor bronze contacts with a gold flash on the mating post (10µ" gold) and matte tin on the solder tail, providing reliable electrical performance and corrosion resistance. The insulation is black Liquid Crystal Polymer (LCP), rated for operating temperatures from -55°C to 125°C with gold plating. Electrical ratings include 3.2A per contact (with 2 pins powered) and voltage ratings of 281 VAC when mated with SQW receptacles or 250 VAC with SQT receptacles. The through-hole mounting ensures robust mechanical attachment to the PCB. This unshrouded header uses a push-pull fastening type and is suitable for a wide range of signal and low-power applications.

TMM-105-01-L-S Quick Information

Product Type: Header, Male Pins
Series: TMM
Canonical Name: Samtec TMM-105-01-L-S 5 Position Single Row 2.00mm Pitch Through Hole Header
Subcategory: Male Pins

TMM-105-01-L-S Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TMM-105-01-L-S Estimated Pricing

Qty Low High
1+ $0.72 $0.72
50+ $0.59 $0.59
100+ $0.48 $0.48
500+ $0.39 $0.39
1,000+ $0.33 $0.33
2,000+ $0.30 $0.30
5,000+ $0.24 $0.24
10,000+ $0.17 $0.17

Estimated market price range - modelled values for guidance only, not live distributor offers.

TMM-105-01-L-S Features

  • 5 positions in single row configuration.
  • 2.00mm pitch for compact designs.
  • Through-hole mounting for reliable connections.
  • Gold flash on post for corrosion resistance.
  • Rated for 3.2A per contact.

TMM-105-01-L-S Applications

  • Board-to-board interconnects in compact electronics.
  • Cable-to-board connections in industrial systems.
  • Prototyping and test fixtures.
  • General purpose signal and power distribution.

TMM-105-01-L-S FAQs

7 frequently asked questions generated from this part’s specifications.
What is the number of positions?

5 positions.

What is the pitch?

2.00mm (0.079").

What is the current rating?

3.2A per contact (2 pins powered).

What is the voltage rating?

281 VAC mated with SQW, 250 VAC with SQT.

What is the mounting type?

Through hole.

What is the operating temperature range?

-55°C to 125°C with gold plating.

What contact finish is available?

Gold flash on post (10µ" gold) and matte tin on tail.
