| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Applications | |
| Approval Agency | |
| Automotive Grade | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Industrial Grade | |
| Input Voltage | |
| Length | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Output Voltage | |
| Power (Watts) | |
| SVHC Present | |
| Termination Style | |
| Type | |
| Voltage | |
| Width |
The Traco Power TML 20103C is a compact, encapsulated industrial AC/DC power supply designed for chassis mounting with screw terminals. It operates with a universal AC input range of 90~264Vac at 47~440Hz, delivering a stable 3.3Vdc output at a maximum current of 4.5A, for a total of 14 Watts of power.
Key electrical specifications include an efficiency of 84% and an isolation voltage of 3 kV. The operating temperature range is -25°C to +70°C, with potential derating. Safety approvals include UL/cUL 60950-1 and IEC/EN 60950-1, with EMI meeting EN 55022 Class B and FCC Level B standards.
Mechanical dimensions are 96.0mm x 54.6mm x 27.7mm. This converter is suitable for ITE (Commercial) applications and features adjustable output and universal input. It has a single output.
Environmental compliance includes RoHS3 compliance and an MSL of 1. The REACH status is unaffected. This power supply is designed for reliable operation in industrial environments.
The output voltage is 3.3Vdc.
The maximum output current is 4.5 Amps.
The maximum power output is 14 Watts.
The input voltage range is 90~264Vac.
The operating temperature range is -25°C to +70°C.
It is designed for chassis mounting.
It has UL/cUL 60950-1 and IEC/EN 60950-1 approvals.
