The Traco Power TML 15105C is a versatile AC/DC converter designed for various applications. It accepts a wide input voltage range of 100-240V AC at 47-63Hz, providing a stable +5V DC output with a maximum current of 3A, resulting in a total power output of 15W. The converter boasts an efficiency of 80% and features universal input capabilities.
Designed for ease of integration, the TML 15105C is an enclosed unit with a chassis mount type, making it suitable for direct installation into equipment. Its dimensions are 96.0mm in length, 54.1mm in width, and 27.4mm in height. The unit is rated for an insulation voltage of 3 kV and operates within a temperature range of -25°C to 60°C, with derating applied at higher temperatures.
This power supply is approved by CE and cURus, adhering to the standard number 60950-1. It is intended for ITE (Commercial) applications and features a single output. The RoHS status is listed as RoHS3 Compliant, Moisture Sensitivity Level (MSL) is 1 Unlimited, and REACH Status is Unaffected, though this data is from the existing database with low confidence.
The output is +5 VDC at 3 A.
The input voltage range is 100-240 VAC at 47-63 Hz.
The operating temperature range is -25°C to 60°C with derating.
The efficiency is 80%.
It is approved to CE and cURus standards per 60950-1.
It is chassis mount.
