| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
28 pcs
|
28 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Applications | |
| Current | |
| Efficiency | |
| Features | |
| Height | |
| Lead Style | |
| Length | |
| Mounting Type | |
| Number of Outputs | |
| Operating Temperature | |
| Power (Watts) | |
| Storage Temperature | |
| Tape & Reel | |
| Type | |
| Voltage | |
| Width |
The Traco Power TMH 0505S is an isolated DC DC converter module designed for commercial ITE (Information Technology Equipment) applications. It provides a single regulated 5V output with a maximum output current of 400mA, delivering up to 2W of power.
Key electrical specifications include a typical efficiency of 76% and an operating temperature range of -40°C to 85°C with derating. The module features short circuit protection (SCP) for enhanced reliability.
The converter is housed in a 7-SIP module with 4 leads and features a through-hole mounting style. Its compact dimensions are 23.8mm x 13.7mm x 8.0mm (0.94" x 0.54" x 0.31"), making it suitable for space-constrained designs.
| Qty | Low | High |
|---|---|---|
| 1+ | $7.17 | $7.17 |
| 10+ | $6.71 | $6.71 |
| 20+ | $6.57 | $6.57 |
| 50+ | $6.52 | $6.52 |
| 100+ | $6.46 | $6.46 |
| 200+ | $6.42 | $6.42 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 5V.
The output current is 400mA.
The power rating is 2W.
The typical efficiency is 76%.
The operating temperature range is -40°C to 85°C with derating.
It comes in a 7-SIP module with 4 leads, through-hole mounting.
The RoHS status is listed as RoHS3 Compliant, but this is unverified.
