The Traco Power TMG 30112 is a 30W encapsulated AC/DC power supply designed for ITE applications. It accepts a universal input voltage range of 90-305Vac or 120-370Vdc, providing a stable 12Vdc output at a maximum current of 2.5A. The unit boasts high efficiency of 89% and features essential protections such as short circuit and over voltage.
This power supply is built with a fully encapsulated plastic casing and offers 3000Vac I/O isolation. It is prepared for Safety Class II and operates reliably within a wide temperature range of -40°C to +70°C, with derating applied at higher temperatures. The TMG 30112 is designed for through-hole mounting and comes in a 5-DIP module package.
Key specifications include a compact size with dimensions of 64.0mm x 45.0mm x 23.5mm. It is manufactured in Taiwan and carries a 3-year warranty from Traco Power. The unit is RoHS3 compliant and has an MSL of 1.
The input voltage range is 90-305 VAC or 120-370 VDC.
The output is 12 VDC at 2.5 A, providing 30 W.
The efficiency is 89%.
The I/O isolation is 3000 VAC.
It includes short circuit and over voltage protection.
The operating temperature range is -40°C to +70°C with derating.
The package is a 5-DIP module with 4 leads, measuring 64.0mm x 45.0mm x 23.5mm.
