TM4C1294NCPDT The Texas Instruments TM4C1294NCPDT is a 32-bit microcontroller based on the Arm Cortex-M4F core. It operates at 120MHz and offers 1MB of Flash memory and 256KB of RAM.
Mfr Part #:

TM4C1294NCPDT

Available from 1 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TM4C1294NCPDT is a 32-bit microcontroller based on the Arm Cortex-M4F core. It operates at 120MHz and offers 1MB of Flash memory and 256KB of RAM.
✓ Total Stock: 3,767 pcs
$ Price Range: $5.52

TM4C1294NCPDT Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
3,767 pcs
On Request
3767 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TM4C1294NCPDT Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Ethernet
Frequency
Operating Temperature Range
SVHC Present
Security Features
USB
View Similar Products (0)

TM4C1294NCPDT Description

Short technical summary and product information.

The Texas Instruments TM4C1294NCPDT is a powerful 32-bit microcontroller designed for embedded applications. It features an Arm Cortex-M4F processor core running at 120MHz, delivering 150 DMIPS performance. This MCU is equipped with 1024 KB of Flash memory and 256 KB of single-cycle System SRAM, providing ample space for code and data.



Connectivity options include 10/100 Ethernet MAC with PHY, USB 2.0 OTG/Host/Device, CAN 2.0 A/B controllers, UART, I2C, and QSSI interfaces. The device also includes advanced features such as cryptographic acceleration, secure debug capabilities, and a floating-point unit.



Packaged in a TQFP form factor with dimensions of 256 mm² (16 mm × 16 mm), the TM4C1294NCPDT operates within a temperature range of -40°C to 105°C. Its robust feature set makes it suitable for a wide range of industrial, consumer, and IoT applications requiring high performance and connectivity.

TM4C1294NCPDT Quick Information

Product Type: Microcontroller
Series: Tiva C Series
Canonical Name: Texas Instruments TM4C1294NCPDT Microcontroller
Subcategory: General-Purpose Microcontrollers

TM4C1294NCPDT Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TM4C1294NCPDT Estimated Pricing

Qty Low High
1+ $5.52 $5.52

Estimated market price range - modelled values for guidance only, not live distributor offers.

TM4C1294NCPDT Features

  • 32-bit Arm Cortex-M4F processor core
  • 120MHz operation with 150 DMIPS performance
  • 1024 KB Flash memory and 256 KB SRAM
  • Integrated 10/100 Ethernet MAC+PHY
  • USB 2.0 OTG/Host/Device support

TM4C1294NCPDT Applications

  • Ideal for industrial automation systems.
  • Suitable for IoT gateway devices.
  • Used in embedded control applications.
  • Supports real-time data processing.

TM4C1294NCPDT FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating temperature range for the TM4C1294NCPDT?

The operating temperature range is -40°C to 105°C.

What type of CPU core does the TM4C1294NCPDT use?

It uses an Arm Cortex-M4F CPU core.

How much Flash memory does the TM4C1294NCPDT have?

It has 1024 KB of Flash memory.

What is the RAM size of the TM4C1294NCPDT?

It has 256 KB of RAM.

Does the TM4C1294NCPDT support Ethernet?

Yes, it features a 10/100 Ethernet MAC with PHY.

What USB version is supported by the TM4C1294NCPDT?

It supports USB 2.0 OTG/Host/Device.

What is the ECCN classification for the TM4C1294NCPDT?

The ECCN classification is EAR99 for both US and EU.
