TM1640 The TM1640 is a LED drive control circuit from TM, designed for electronic scales and small home appliances. It offers an 8-section by 16-bit display mode and a dual-line serial interface.
Mfr Part #:

TM1640

Available from 1 distributors
Mfr Name: TM
TM
The TM1640 is a LED drive control circuit from TM, designed for electronic scales and small home appliances. It offers an 8-section by 16-bit display mode and a dual-line serial interface.
✓ Total Stock: 8,969 pcs
$ Price Range: $1.92

TM1640 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Optech Co.,Limited ✓
Non-Authorised Inventory information
8,969 pcs
On Request
8969 pcs On Request 1 On Request On Request 21+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TM1640 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Frequency
Operating Temperature
Power Consumption
Storage Temperature
View Similar Products (0)

TM1640 Description

Short technical summary and product information.

The TM1640 is an LED (Light Emitting Diode Display) drive control circuit integrating MCU digital interface, digital latch, and LED high voltage drive circuit. It is manufactured using PowerCMOS technique and operates with a logic power voltage range of -0.5 to 7.0 V, typically 5V.



Key features include an 8-section by 16-bit display mode supporting common cathode digital tube output, an adjustable brightness circuit with 8 duty cycle levels, and a dual-line serial interface (CLK, DIN). The device has a built-in RC oscillator operating at 450 KHz ±5%, a power-on reset circuit, and an auto-blanking circuit.



Available in SOP28 and SSOP28 packages, the TM1640 is suitable for applications requiring display drive in electronic scales and other small home appliances. It operates within a temperature range of -40 to +85 °C.

TM1640 Quick Information

Product Type: LED Drive Control Circuit
Canonical Name: TM1640 LED Drive Control Circuit
Subcategory: Voltage Regulators - Linear Regulator Controllers

TM1640 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TM1640 Estimated Pricing

Qty Low High
1+ $1.92 $1.92

Estimated market price range - modelled values for guidance only, not live distributor offers.

TM1640 Features

  • 8 sections x 16 bits display mode
  • Adjustable brightness circuit with 8 levels
  • Dual-line serial interface (CLK, DIN)
  • Built-in RC oscillator at 450 KHz
  • SOP28 and SSOP28 package options

TM1640 Applications

  • Display drive for electronic scales
  • Control for small home appliances
  • LED segment and grid driving
  • Custom display applications

TM1640 FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the TM1640?

The logic power voltage for the TM1640 ranges from -0.5 to 7.0 V, with a typical value of 5 V.

What display modes does the TM1640 support?

The TM1640 supports an 8 sections by 16 bits display mode for common cathode digital tubes.

What is the operating temperature range of the TM1640?

The TM1640 operates within a temperature range of -40 to +85 °C.

What packages are available for the TM1640?

The TM1640 is available in SOP28 and SSOP28 packages.
