Mfr Part #:

TLW-140-06-G-S

Samtec TLW-140-06-G-S is a 40-position, single row, through hole header connector with 2.54mm pitch. It features gold-plated phosphor bronze contacts and an unshrouded design.

✓ Total Stock: 2,293 pcs

$ Price Range: $3.53 - $11.83

TLW-140-06-G-S Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Hybrid Electronics ✓ Non-Authorised Inventory information	2,293 pcs On Request	2293 pcs	On Request	1	On Request	On Request	616	On Request	On Request

TLW-140-06-G-S Description

Short technical summary and product information.

The Samtec TLW-140-06-G-S is a rectangular header connector designed for board-to-board or cable applications. It features 40 male pin contacts arranged in a single row with a 2.54mm (0.100") pitch. The connector uses through-hole mounting with solder termination, making it suitable for permanent PCB attachment. The unshrouded design allows for flexible mating with various receptacles. Contacts are made of phosphor bronze with a gold finish (10.0µin) for reliable conductivity and corrosion resistance. The insulator is black liquid crystal polymer (LCP) with an insulation height of 1.52mm. The overall contact length is 7.62mm, with a mating pin length of 2.67mm. Each contact is rated for 5.2A current. The operating temperature range is -55°C to 125°C. The push-pull fastening type ensures easy insertion and removal. This connector is RoHS3 compliant (unverified) and has an MSL of 1 (unlimited). It is commonly used in applications requiring reliable interconnections in industrial, automotive, and consumer electronics.

TLW-140-06-G-S Quick Information

Product Type: Header Connector

Series: TLW

Canonical Name: Header, Male Pins, 40 Position, Single Row, Through Hole, 2.54mm Pitch

Subcategory: Male Pins

TLW-140-06-G-S Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TLW-140-06-G-S Estimated Pricing

Qty	Low	High
1+	$11.83	$11.83
10+	$9.60	$9.60
25+	$8.15	$8.15
50+	$8.14	$8.14
100+	$7.18	$7.18
250+	$7.17	$7.17
500+	$6.79	$6.79
1,000+	$4.34	$4.34
2,000+	$3.53	$3.53

Estimated market price range - modelled values for guidance only, not live distributor offers.

TLW-140-06-G-S Features

40 positions in single row.
2.54mm pitch for standard spacing.
Through-hole mounting for secure attachment.
Gold-plated phosphor bronze contacts.
Operating temperature from -55°C to 125°C.

TLW-140-06-G-S Applications

Board-to-board interconnection in PCBs.
Cable-to-board connections in industrial equipment.
Prototyping and test fixtures.
Consumer electronics requiring reliable headers.

TLW-140-06-G-S FAQs

7 frequently asked questions generated from this part’s specifications.

How many positions does the TLW-140-06-G-S have?

40 positions.

What is the pitch of this header?

2.54mm (0.100").

What is the current rating per contact?

5.2A per contact.

What is the mounting type?

Through hole with solder termination.

What is the operating temperature range?

-55°C to 125°C.

What is the contact finish?

Gold, 10.0µin (0.25µm) thickness.

Is this connector RoHS compliant?

RoHS3 compliant (unverified).

Category	Headers, Male Pins
Manufacturer Name	Samtec Inc.
Connector Type	Header
Contact Finish	Gold
Contact Finish Thickness	10.0µin (0.25µm)
Contact Length	2.67mm (0.105")
Contact Material	Phosphor Bronze
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	5.2A per Contact
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	1.52mm (0.060")
Insulation Material	Liquid Crystal Polymer (LCP)
Lead Spacing	2.54 mm
Mounting Type	Through Hole
Number of Positions	40
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature	-55°C ~ 125°C
Overall Contact Length	7.62mm (0.300")
Pitch	2.54mm (0.100")
Shrouding	Unshrouded
Style	Board to Board or Cable
Tape & Reel	No
Termination	Solder
