| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
7,295 pcs
|
7295 pcs | On Request | 1 | On Request | On Request | 22+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Halogen Free | |
| Industrial Grade | |
| Lead Spacing | |
| Lead Style | |
| Medical Grade | |
| Military Grade | |
| Mounting Type | |
| Operating Temperature | |
| Output Current | |
| SVHC Present | |
| Storage Temperature | |
| Tape & Reel | |
| Temperature Coefficient |
The TLVH432QDBZR is an adjustable precision shunt regulator from Texas Instruments, designed for low-voltage applications. It features a reference voltage of 1.24V and allows for an adjustable output voltage ranging from 1.24V up to 18V using two external resistors.
This device boasts a maximum initial accuracy of 1.5% at 25°C and operates over a wide cathode current range from 100µA to 70mA. The temperature coefficient is a maximum of 138 ppm/°C, ensuring stable performance across its operating temperature range of -40°C to 125°C.
The TLVH432QDBZR is available in multiple package options, including SOT-23-3, SOT-89, and the ultra-small SC-70 package, which offers a 40% smaller footprint compared to the SOT-23-3. Its typical output impedance is 0.25Ω.
This shunt regulator is suitable for various power management applications requiring a stable and adjustable voltage reference. Its wide operating current and voltage capabilities make it a versatile component for designers.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.27 | $0.27 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage can be set to any value between 1.24V and 18V.
The maximum initial accuracy is 1.5% at 25°C.
The operating temperature range is -40°C to 125°C.
The TLVH432QDBZR is available in SOT-23-3, SOT-89, and SC-70 packages.
The minimum cathode current for regulation is 60µA.
