| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
452,000 pcs
|
452000 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Lead Style | |
| Mounting Type | |
| Number of Pins | |
| Operating Temperature | |
| Output Current | |
| Output Voltage | |
| Temperature Coefficient |
The TLVH431ACDBZT is a low-voltage, 3-terminal adjustable precision shunt regulator manufactured by Texas Instruments. It offers specified thermal stability over industrial and commercial temperature ranges, operating from -40°C to 125°C.
Key electrical characteristics include an adjustable output voltage from 1.24V up to 18V, with an initial accuracy of 1% at 25°C. The device supports a wide operating cathode current range from 100 µA to 70 mA, with a minimum cathode current for regulation of 60 µA. It exhibits a typical output impedance of 0.25 Ω and a maximum temperature coefficient of 138 ppm/°C.
This shunt regulator is supplied in a SOT-23 surface-mount package, measuring 6.9204 mm² with dimensions of 2.92 mm x 2.37 mm. Its low-voltage operation down to 1.24V makes it suitable for various power management applications requiring precise voltage referencing.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.41 | $0.41 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is adjustable from 1.24 V to 18 V.
The initial accuracy is 1% at 25°C.
The operating temperature range is -40°C to 125°C.
It is available in a 3-pin SOT-23 surface-mount package.
The minimum cathode current for regulation is 60 µA.
The maximum output current is 70 mA.
The typical output impedance is 0.25 Ω.
