TLV9002IDR The Texas Instruments TLV9002IDR is a dual, 5.5-V, 1-MHz operational amplifier designed for cost-optimized applications. It features rail-to-rail input and output.
Mfr Part #:

TLV9002IDR

Available from 3 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TLV9002IDR is a dual, 5.5-V, 1-MHz operational amplifier designed for cost-optimized applications. It features rail-to-rail input and output.
✓ Total Stock: 302,888 pcs
$ Price Range: $0.21

TLV9002IDR Available from 3 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Romaks Technologies ✓
Non-Authorised Inventory information
258,286 pcs
On Request
258286 pcs On Request 1 On Request On Request On Request On Request On Request
Fe Components ✓
Non-Authorised Inventory information
42,338 pcs
On Request
42338 pcs On Request 1 On Request On Request On Request On Request On Request
Xingangxin ✓
Non-Authorised Inventory information
2,264 pcs
On Request
2264 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TLV9002IDR Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Architecture
Automotive Grade
Features
Industrial Grade
Lead Spacing
Medical Grade
Military Grade
Number of Channels
Slew Rate
Storage Temperature
View Similar Products (0)

TLV9002IDR Description

Short technical summary and product information.

The TLV9002IDR from Texas Instruments is a cost-optimized, dual operational amplifier with a 1-MHz gain-bandwidth product. It operates over a wide supply voltage range from 1.8 V to 5.5 V, making it suitable for various low-voltage applications.



This amplifier boasts rail-to-rail input and output capabilities, allowing for maximum dynamic range. Key electrical characteristics include a typical slew rate of 2 V/µs and a low quiescent current of 0.06 mA per channel. The input offset voltage is typically low, and it offers good common-mode rejection.



Designed with features like EMI hardening and a shutdown mode, the TLV9002IDR is versatile. It is available in multiple small-footprint packages, including DSBGA, X2QFN, WSON, SOT-23-THN, TSSOP, VSSOP, and SOIC, facilitating compact designs. Its architecture is CMOS, contributing to its low power consumption.

TLV9002IDR Quick Information

Product Type: Operational Amplifier
Canonical Name: TLV9002 Dual Operational Amplifier
Subcategory: Comparator

TLV9002IDR Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TLV9002IDR Estimated Pricing

Qty Low High
1+ $0.21 $0.21

Estimated market price range - modelled values for guidance only, not live distributor offers.

TLV9002IDR Features

  • Dual operational amplifier for cost-optimized applications.
  • 1-MHz gain-bandwidth product.
  • 1.8-V to 5.5-V operating supply voltage.
  • Rail-to-rail input and output.
  • Low quiescent current per channel.

TLV9002IDR Applications

  • Suitable for low-voltage applications.
  • Ideal for cost-sensitive designs.
  • Enables compact electronic circuits.
  • Used in battery-powered devices.

TLV9002IDR FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range for the TLV9002IDR?

The TLV9002IDR operates from a minimum supply voltage of 1.8 V to a maximum of 5.5 V.

What is the gain-bandwidth product of the TLV9002IDR?

The typical gain-bandwidth product for the TLV9002IDR is 1 MHz.

What is the slew rate of the TLV9002IDR?

The typical slew rate of the TLV9002IDR is 2 V/µs.

What is the maximum input offset voltage at 25°C for the TLV9002IDR?

The maximum input offset voltage at 25°C for the TLV9002IDR is 1.5 mV.

What is the quiescent current per channel for the TLV9002IDR?

The typical quiescent current per channel for the TLV9002IDR is 0.06 mA.

What is the operating temperature range of the TLV9002IDR?

The TLV9002IDR operates from -40°C to 125°C.

Does the TLV9002IDR have rail-to-rail input and output?

Yes, the TLV9002IDR features rail-to-rail input and output.
