TLV70033DCKR
Texas Instruments
The Texas Instruments TLV70033DCKR is a 200-mA low-dropout linear voltage regulator designed for portable devices. It offers high PSRR and low quiescent current.
| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
237,895 pcs
|
237895 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Noise | |
| Operating Temperature | |
| Output Current | |
| Thermal Resistance |
The Texas Instruments TLV70033 is a 200-mA, low-quiescent current, low-dropout linear voltage regulator. It is designed for portable applications requiring stable power with minimal noise and high power supply rejection ratio (PSRR).
The TLV70033 operates with an input voltage range of 2 V to 5.5 V and provides fixed output voltages from 1.2 V to 3.6 V. Key electrical specifications include a typical quiescent current of 30 µA, a noise level of 48 µVrms, and a PSRR of 51 dB at 100 kHz. The dropout voltage is typically 175 mV at 200 mA output current.
This regulator is available in compact packages such as SOT-23, WSON, and SC-70, making it suitable for space-constrained designs. It features enable functionality, thermal shutdown, and overcurrent protection for enhanced reliability. The device is stable with a minimum load capacitance of 0.1 µF.
Applications for the TLV70033 include battery-powered devices, portable electronics, and other systems requiring efficient and stable voltage regulation. Its low quiescent current and small footprint contribute to longer battery life and reduced board space.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.28 | $0.28 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The maximum input voltage for the TLV70033 is 5.5 V.
The TLV70033 can provide a maximum output current of 0.2 A.
The TLV70033 is available in fixed output voltages including 1.2, 1.3, 1.5, 1.8, 1.9, 2.2, 2.5, 2.8, 2.9, 3, 3.1, 3.2, 3.3, and 3.6 V.
The typical quiescent current for the TLV70033 is 0.03 mA.
The typical dropout voltage for the TLV70033 is 175 mV.
The TLV70033 operates within a temperature range of -40 to 125 °C.
The TLV70033 is available in SOT-SC70, WSON, and SOT-23 package types.
