TLE9879QXA40 The Infineon TLE9879QXA40 is a microcontroller with an Arm Cortex-M3 core, designed for automotive applications. It features 128KB of flash memory and a LIN 2.2 transceiver.
Mfr Part #:

TLE9879QXA40

Available from 2 distributors
Mfr Name: Infineon
Infineon
The Infineon TLE9879QXA40 is a microcontroller with an Arm Cortex-M3 core, designed for automotive applications. It features 128KB of flash memory and a LIN 2.2 transceiver.
✓ Total Stock: 1,086 pcs

TLE9879QXA40 Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
1,077 pcs
On Request
1077 pcs On Request 1 On Request On Request On Request On Request On Request
PROSOFT ELECTRONICS ✓
Non-Authorised Inventory information
9 pcs
On Request
9 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TLE9879QXA40 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Industrial Grade
Interface
Military Grade
Operating Temperature
Operating Voltage
Package / Case
View Similar Products (0)

TLE9879QXA40 Description

Short technical summary and product information.

The Infineon MOTIX™ TLE9879QXA40 is a 32-bit microcontroller based on the Arm Cortex-M3 core, specifically developed for automotive applications requiring BLDC MOSFET driver functionality and LIN communication.



This device is equipped with 128 KB of flash memory and 6 KB of RAM, providing sufficient resources for embedded control tasks. It includes an on-chip oscillator and PLL for clock generation, a MOSFET driver with charge pump, and a LIN 2.2 transceiver for in-vehicle networking.



For motor control applications, it features a high-speed operational amplifier for current sensing via a shunt resistor. The operating voltage range is from 5.5 V to 28 V, and it is qualified for automotive applications according to AEC-Q100/101 standards, with an operating temperature range of -40°C to +150°C.



The TLE9879QXA40 is available in a VQFN-48 package. Potential applications include wipers, auxiliary pumps, fans, window lifts, sunroofs, and tailgates.

TLE9879QXA40 Quick Information

Product Type: Microcontroller
Series: TLE9879QXA40
Canonical Name: Infineon MOTIX™ TLE9879QXA40 Arm Cortex-M3 Microcontroller with LIN and BLDC MOSFET driver
Subcategory: Motor Control SoC/SiP

TLE9879QXA40 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected
Lead Free: Yes

TLE9879QXA40 Features

  • 32-bit Arm Cortex-M3 core
  • 128 KB flash and 6 KB RAM
  • Integrated LIN 2.2 transceiver
  • Automotive qualified per AEC-Q100/101
  • Wide operating voltage range

TLE9879QXA40 Applications

  • Ideal for automotive wiper systems
  • Suitable for auxiliary pump control
  • Used in automotive fan applications
  • Applicable for window lift systems
  • Can be used for sunroof control

TLE9879QXA40 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the TLE9879QXA40?

5.5 V to 28 V.

What is the operating temperature range?

-40°C to +150°C.

What package does the TLE9879QXA40 come in?

VQFN-48.

What core architecture does this device use?

ARM Cortex-M3.

What memory does it have?

128 KB Flash and 6 KB RAM.

Is it qualified for automotive applications?

Yes, AEC-Q100/101 qualified.

What communication interface is supported?

LIN 2.2.
