TLE9255WSK The Infineon TLE9255WSK is an HS CAN Transceiver with Partial Networking, supporting data rates up to 5Mbit/s for CAN FD. It offers excellent ESD robustness and is designed for automotive applications.
Mfr Part #:

TLE9255WSK

Available from 2 distributors
Mfr Name: Infineon
Infineon
The Infineon TLE9255WSK is an HS CAN Transceiver with Partial Networking, supporting data rates up to 5Mbit/s for CAN FD. It offers excellent ESD robustness and is designed for automotive applications.
✓ Total Stock: 12,303 pcs

TLE9255WSK Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
6,216 pcs
On Request
6216 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
6,087 pcs
On Request
6087 pcs On Request 1 On Request On Request 23+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TLE9255WSK Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Package / Case
SVHC Present
View Similar Products (0)

TLE9255WSK Description

Short technical summary and product information.

The Infineon TLE9255WSK is a high-speed CAN transceiver designed for automotive and industrial applications. It fully complies with ISO 11898-2 (2016) and supports standard HS CAN data rates up to 1Mbit/s, as well as CAN FD data rates up to 5Mbit/s.



This transceiver provides a very low level of electromagnetic emission, allowing operation without a common mode choke. It features excellent ESD robustness of ±10 kV according to IEC 61000-4-2 and includes fail-safe features such as TxD timeout and overtemperature shutdown. The device supports partial networking functions and CAN FD tolerant features, enabling the use of microcontrollers not capable of CAN FD.



The TLE9255WSK is available in PG-DSO-14 or PG-TSON-14 packages. It is qualified for automotive applications according to AEC-Q100 and is RoHS compliant.

TLE9255WSK Quick Information

Product Type: CAN Transceiver
Series: TLE9255
Canonical Name: TLE9255WSK HS CAN Transceiver with Partial Networking
Subcategory: HS CAN Transceiver with Partial Networking

TLE9255WSK Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TLE9255WSK Features

  • Compliant to ISO 11898-2 (2016)
  • CAN FD data rates up to 5 MBit/s
  • Excellent ESD robustness ±10 kV
  • Low electromagnetic emission
  • Qualified for automotive applications

TLE9255WSK Applications

  • HS CAN networks in automotive
  • HS CAN networks in industrial
  • CAN FD tolerant applications

TLE9255WSK FAQs

5 frequently asked questions generated from this part’s specifications.
What are the data rates supported by the TLE9255WSK?

The TLE9255WSK supports HS CAN standard data rates up to 1Mbit/s and CAN FD data rates up to 5Mbit/s.

What is the ESD protection level for the TLE9255WSK?

The TLE9255WSK has excellent ESD robustness of ±10 kV according to IEC 61000-4-2.

What package options are available for the TLE9255WSK?

The TLE9255WSK is available in PG-DSO-14 or PG-TSON-14 packages.

Is the TLE9255WSK RoHS compliant?

Yes, the TLE9255WSK is RoHS3 Compliant.

What is the Moisture Sensitivity Level (MSL) for the TLE9255WSK?

The Moisture Sensitivity Level (MSL) for the TLE9255WSK is 1 Unlimited.
