TLE9201SGAUMA1 The Infineon Technologies TLE9201SGAUMA1 is a 6A half bridge driver designed for DC motor control and general-purpose applications. It features an SPI interface and operates within a voltage range of 5V to 28V.
Mfr Part #:

TLE9201SGAUMA1

Available from 1 distributors
Mfr Name: Infineon Technologies
Infineon Technologies
The Infineon Technologies TLE9201SGAUMA1 is a 6A half bridge driver designed for DC motor control and general-purpose applications. It features an SPI interface and operates within a voltage range of 5V to 28V.
✓ Total Stock: 3,421 pcs
$ Price Range: $4.19

TLE9201SGAUMA1 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Xingangxin ✓
Non-Authorised Inventory information
3,421 pcs
On Request
3421 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TLE9201SGAUMA1 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Applications
Current
Fault Protection
Interface
Load Type
Mounting Type
Operating Temperature
Output Configuration
Rds On (Typ)
Supplier Device Package
Technology
Voltage
View Similar Products (0)

TLE9201SGAUMA1 Description

Short technical summary and product information.

The TLE9201SGAUMA1 from Infineon Technologies is a robust 6A H-Bridge driver IC, specifically designed for automotive power applications. This component integrates two half-bridge output stages, enabling efficient control of DC motors and other general-purpose loads. It supports a wide operating voltage range from 5V to 28V, making it versatile for various automotive systems.



The device communicates via a Serial Peripheral Interface (SPI) and Pulse Width Modulation (PWM) signals, allowing for precise control and diagnostics. Key protection features include detection for open loads, over-temperature conditions, short circuits, and undervoltage lockout (UVLO), ensuring system reliability and safety. The TLE9201SGAUMA1 is built using Power MOSFET technology, offering low on-resistance (100mOhm typical for both high-side and low-side) for improved efficiency.



Packaged in a PG-DSO-12-17 (12-BSOP) with an exposed pad for enhanced thermal dissipation, this surface-mount component is suitable for demanding environments. Its operating temperature range is -40°C to 150°C (TJ). The TLE9201SGAUMA1 is designed for applications requiring reliable and protected motor driving capabilities.

TLE9201SGAUMA1 Quick Information

Product Type: Half Bridge Driver
Canonical Name: TLE9201SGAUMA1 6A H-Bridge with SPI
Subcategory: Power Management ICs

TLE9201SGAUMA1 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TLE9201SGAUMA1 Estimated Pricing

Qty Low High
1+ $4.19 $4.19

Estimated market price range - modelled values for guidance only, not live distributor offers.

TLE9201SGAUMA1 Features

  • 6A continuous output current capability.
  • Wide 5V to 28V operating voltage range.
  • SPI and PWM interface for control.
  • Integrated fault protection features.
  • Surface mount PG-DSO-12-17 package.

TLE9201SGAUMA1 Applications

  • Driving brushed DC motors.
  • General purpose half-bridge switching.
  • Automotive actuator control.
  • Industrial motor drives.
  • Power supply conversion stages.

TLE9201SGAUMA1 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the operating voltage range of the TLE9201SGAUMA1?

5V to 28V.

What package does the TLE9201SGAUMA1 use?

PG-DSO-12-17 (12-BSOP with exposed pad).

What is the operating temperature range?

-40°C to 150°C (junction).

What is the continuous current rating?

6A.

Does the TLE9201SGAUMA1 include fault protection?

Yes, it includes open load detect, over temperature, short circuit, and UVLO protection.

What control interfaces does it support?

PWM and SPI.

What is the typical on-resistance?

100mOhm for both high-side and low-side.
