The Infineon TLE8386-2EL is a basic smart boost controller IC designed for step-up conversion applications. It operates within a wide input voltage range from 4.75 V to 45 V, providing constant current and constant voltage regulation.
Key features include a flexible switching frequency adjustable from 100 kHz to 700 kHz, which can be synchronized with an external clock. The device offers very low shutdown current consumption, less than 2 µA, thanks to an enable function. It also incorporates integrated protection features such as output overvoltage protection and overtemperature shutdown.
The TLE8386-2EL is suitable for harsh automotive environments and is qualified according to AEC-Q100. It is available in a thermally enhanced PG-SSOP-14 package. The integrated soft-start feature, adjustable by an external capacitor, helps limit current peaks and voltage overshoot during startup.
Potential applications include step-up converters, voltage stabilization during cold cranking, SEPIC converters, and flyback converters.
The input voltage range is 4.75V to 45V.
The TLE8386-2EL is packaged in a PG-SSOP-14.
The switching frequency is adjustable from 100kHz to 700kHz and can be synchronized with an external clock.
Yes, the device provides constant current regulation in addition to constant voltage regulation.
The shutdown current is less than 2µA.
The device includes output overvoltage protection and overtemperature shutdown.
Yes, the device is AEC-Q100 qualified for automotive applications.
