| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
22,325 pcs
|
22325 pcs | On Request | 1 | On Request | On Request | 99+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Voltage | |
| Output Current | |
| Package / Case | |
| Supply Voltage |
The TLE4727 from Siemens is a bipolar monolithic IC specifically designed for driving bipolar stepper motors, DC motors, and other inductive loads that operate on constant current. This integrated circuit combines driver, control logic, and current control (chopper) on a single chip.
Key features include 2 x 0.7 amp outputs per phase, fast free-wheeling diodes, and a maximum supply voltage of 45 V. The device operates at voltages up to 16 V and provides a stabilized 5 V output for logic supply, capable of powering external components up to 5 mA. The outputs are free of crossover current and short-circuit proof.
The TLE4727 is housed in a P-DIP-20-6 package, suitable for through-hole mounting. Its design allows for direct microprocessor control, enabling programmable direction and current control for each phase independently. An error flag signals malfunctions such as overload, open load, or overtemperature, aiding in troubleshooting.
This IC is suitable for applications requiring precise control of stepper motors, such as in automation, robotics, and industrial equipment where reliable motor driving is essential.
The maximum supply voltage for the TLE4727 is 45 V.
The TLE4727 provides 0.7 A of output current per phase.
The TLE4727 is available in a P-DIP-20-6 package.
The TLE4727 operates at voltages up to 16 V.
Yes, the TLE4727 has a stabilized 5 V output for logic supply, capable of up to 5 mA.
