The Infineon TLE4270-2D is a 5V low drop fixed voltage regulator, part of the OPTIREG™ linear family. It is designed for general automotive applications and is qualified according to AEC-Q100.
Key electrical features include a nominal output voltage of 5V with a tolerance of ±2%. It can supply an output current of up to 650mA. The device accepts an input voltage up to 42V, with overvoltage protection up to 65V for short durations (≤ 400 ms). It also incorporates integrated overtemperature protection, reverse polarity protection, and short-circuit proofing.
This voltage regulator is suitable for use in automotive electronics. It features reset functionality with adjustable reset time. The device is supplied in a PG-TO252-5 surface mount package.
| Qty | Low | High |
|---|---|---|
| 1+ | $2.02 | $2.02 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The output voltage is 5V.
The output current capability is 650mA.
The input voltage range is up to 42V.
Yes, it has overvoltage protection up to 65V (≤ 400 ms).
The TLE4270-2D is in a PG-TO252-5 package.
