TLC7701QD The Texas Instruments TLC7701QD is a micropower supply voltage supervisor providing reset control. It operates within a 2V to 6V supply voltage range and features a 1.1ms minimum reset timeout.
Mfr Part #:

TLC7701QD

Available from 2 distributors
Mfr Name: Texas Instruments
Texas Instruments
The Texas Instruments TLC7701QD is a micropower supply voltage supervisor providing reset control. It operates within a 2V to 6V supply voltage range and features a 1.1ms minimum reset timeout.
✓ Total Stock: 5,794 pcs
$ Price Range: $0.75

TLC7701QD Available from 2 distributors

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Components Technology Group, Inc. ✓
Non-Authorised Inventory information
5,750 pcs
On Request
5750 pcs On Request 1 On Request On Request On Request On Request On Request
Optech Co.,Limited ✓
Non-Authorised Inventory information
44 pcs
On Request
44 pcs On Request 1 On Request On Request 13+ On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TLC7701QD Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
AEC Qualified
Automotive Grade
Lead Spacing
Lead Style
Mounting Type
Number of Voltages Monitored
Operating Temperature
Operating Voltage
Output
Reset
Reset Timeout
SVHC Present
Supplier Device Package
Type
Voltage
View Similar Products (0)

TLC7701QD Description

Short technical summary and product information.

The TLC7701QD from Texas Instruments is a micropower supply voltage supervisor designed for microcomputer and microprocessor systems. It provides essential reset control functions, including power-on reset generation and automatic reset generation after a voltage drop.



This device features a precision voltage sensor and a temperature-compensated voltage reference. The supply voltage range is from 2V to 6V, with a defined RESET output available when VDD is greater than or equal to 1V. The reset timeout is a minimum of 1.1ms, and the output type is Push-Pull, Totem Pole. The operating temperature range is -40°C to 125°C (TA).



The TLC7701QD is housed in an 8-SOIC package, suitable for surface mount applications. It monitors a single voltage and offers active high/active low reset functionality. The maximum supply current is a low 16 µA, making it suitable for power-sensitive applications.



This supervisor is also designed to support power-down control for static RAM with battery backup. The delay time can be programmed by an external capacitor, offering flexibility in system design.

TLC7701QD Quick Information

Product Type: Voltage Supervisor
Canonical Name: TLC7701QD Micropower Supply Voltage Supervisor
Subcategory: Supervisors

TLC7701QD Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TLC7701QD Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

TLC7701QD Features

  • Micropower supply voltage supervisor IC.
  • Operates from 2V to 6V supply voltage.
  • Provides 1.1ms minimum reset timeout.
  • Surface mount 8-SOIC package.
  • Wide -40°C to 125°C operating temperature.

TLC7701QD Applications

  • Used in microcomputer systems.
  • Suitable for microprocessor systems.
  • Supports static RAM with battery backup.
  • Provides power-on reset generation.
  • Automatic reset after voltage drop.

TLC7701QD FAQs

7 frequently asked questions generated from this part’s specifications.
What is the supply voltage range of the TLC7701QD?

2 V to 6 V.

What is the operating temperature range?

-40°C to 125°C (TA), with extended capability up to -55°C to 125°C.

What package is the TLC7701QD available in?

8-SOIC (0.154", 3.90mm Width), surface mount.

What is the reset timeout delay?

1.1 ms minimum.

What is the maximum supply current?

16 µA maximum.

What output types are supported?

Push-pull, totem pole, active high and active low.

How many voltages does the TLC7701QD monitor?

1 voltage.
