| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,400 pcs
|
2400 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| CMRR, PSRR (Typ) | |
| Current | |
| Current - Quiescent (Max) | |
| Lead Spacing | |
| Mounting Type | |
| Number of Elements | |
| Operating Temperature | |
| Operating Voltage | |
| Output Type | |
| Propagation Delay (Max) | |
| Supplier Device Package | |
| Tape & Reel | |
| Type | |
| Voltage |
The TL3116CD is a general-purpose comparator IC manufactured by Texas Instruments. It is designed for high-speed operation with a maximum propagation delay of 12ns. This comparator can operate from a single 5V supply or a split ±5V supply, offering flexibility in power configurations.
Key electrical characteristics include a low input offset voltage and complementary TTL-compatible outputs. The input common-mode voltage range includes the negative rail, making it suitable for ground-sensing applications. The device also features output latch capability.
The TL3116CD is available in an 8-SOIC surface-mount package. Its operating temperature range is 0°C to 70°C. This comparator is a functional replacement for the LT1116, providing high-speed performance with reduced power consumption.
This component is suitable for various digital interface applications where fast switching and precise comparison are required.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.36 | $0.36 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The TL3116CD operates from a single 5V supply or a split ±5V supply, with a voltage range of 5V to 10V.
The maximum propagation delay for the TL3116CD is 12ns.
The TL3116CD features complementary, Push-Pull, TTL outputs.
The TL3116CD has an operating temperature range of 0°C to 70°C.
The TL3116CD is available in an 8-SOIC package.
