Mfr Part #:

THGBMTG5D1LBAIL

The Kioxia THGBMTG5D1LBAIL is a 4GB eMMC 5.0 embedded flash memory module. It features 15nm NAND technology and an HS400 interface.

✓ Total Stock: 8,062 pcs

$ Price Range: $1.28

THGBMTG5D1LBAIL Available from 2 distributors

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Optech Co.,Limited ✓ Non-Authorised Inventory information	4,031 pcs On Request	4031 pcs	On Request	1	On Request	On Request	23+	On Request	On Request
Smaxon Electronics ✓ Non-Authorised Inventory information	4,031 pcs On Request	4031 pcs	On Request	1	On Request	On Request	23+	On Request	On Request

THGBMTG5D1LBAIL Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	Memory
Manufacturer Name	Kioxia America, Inc.
Mounting Type	Surface Mount
Operating Temperature	-25°C to +85°C
Operating Voltage	3.3V
SVHC Present	Not Present

View Similar Products (0)

THGBMTG5D1LBAIL Description

Short technical summary and product information.

The Kioxia THGBMTG5D1LBAIL is a 4GB embedded MultiMediaCard (eMMC) flash memory module, utilizing 15nm NAND technology with process improvements. This component is designed for applications requiring reliable storage, operating at a standard 3.3V VCC and within a temperature range of -25°C to +85°C.

The eMMC 5.0 interface supports HS400 mode, achieving headline read speeds of 152 MB/s. The part number THGBMTG5D1LBAIL decodes to specific characteristics, with the 'T' in the fifth position indicating Kioxia's refined 15nm planar NAND generation. This distinguishes it from earlier 'D' (19nm) and 'N' (15nm) generations, impacting endurance and data retention.

Packaged in a 153-ball WFBGA measuring 11.5 mm x 13 mm, the THGBMTG5D1LBAIL is suitable for surface-mount applications. It consists of a single NAND die, integrated with a controller, providing a complete storage solution. From the host's perspective, it is functionally interchangeable with other generations, but the NAND process node affects long-term reliability characteristics.

THGBMTG5D1LBAIL Quick Information

Product Type: eMMC Flash Memory

Canonical Name: Kioxia THGBMTG5D1LBAIL 4GB eMMC 5.0

Subcategory: Flash Memory

THGBMTG5D1LBAIL Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

THGBMTG5D1LBAIL Estimated Pricing

Qty	Low	High
1+	$1.28	$1.28

Estimated market price range - modelled values for guidance only, not live distributor offers.

THGBMTG5D1LBAIL Features

4GB eMMC 5.0 embedded flash memory.
Utilizes refined 15nm planar NAND technology.
Supports HS400 interface speed.
Operates at 3.3V over -25°C to +85°C.
Compact 153-WFBGA surface mount package.

THGBMTG5D1LBAIL Applications

Embedded systems requiring flash storage.
Consumer electronics devices.
Industrial control systems.
Automotive applications.

THGBMTG5D1LBAIL FAQs

7 frequently asked questions generated from this part’s specifications.

What is the operating voltage of the THGBMTG5D1LBAIL?

The operating voltage is 3.3 V.

What package type does the THGBMTG5D1LBAIL use?

153-WFBGA (Ball Grid Array) package.

What is the operating temperature range?

-25°C to +85°C.

How much storage capacity does the THGBMTG5D1LBAIL provide?

32 GBits (4 GB) user capacity, using a single die.

What interface does this eMMC device use?

MMC/eMMC interface with HS400 speed mode.

What is the maximum read speed?

152 MB/s.

What NAND technology is used in this part?

15nm planar NAND (revised/improved version) from Kioxia.
