| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
4 pcs
|
4 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Data Rate | |
| Mounting Type | |
| Power Consumption | |
| Supply Voltage |
The Thomson-CSF THC63LVDM83A is a high-performance LVDS transmitter designed to convert 28 bits of CMOS/TTL data into an LVDS data stream. It operates within a wide frequency range of 20 to 85MHz, making it suitable for various display resolutions like VGA, SVGA, XGA, and SXGA. The device features a narrow bus, reducing cable size, and offers low EMI due to its 345mV swing LVDS output.
This transmitter supports a data rate of up to 595 Mbps per LVDS channel and a throughput of 298 Megabytes per second. It includes features like on-chip input jitter filtering and supports spread spectrum clock generation. The THC63LVDM83A operates on a single 3.3V supply with low power consumption of 125mW typical. It is available in a low-profile 56-lead TSSOP package, suitable for surface mount applications.
The THC63LVDM83A is an improved replacement for the National Semiconductor DS90C383/384. It is designed for applications requiring efficient and reliable data transmission between a host and an LCD panel, commonly found in display systems.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.94 | $1.94 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The THC63LVDM83A operates within a frequency range of 20 to 85MHz.
The THC63LVDM83A requires a single 3.3V supply.
The THC63LVDM83A is available in a 56-lead TSSOP package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
The REACH status is REACH Unaffected.
