Mfr Part #:

TEXAS

The Texas Instruments AFE1302 is an Analog Front-End IC designed for ADSL systems. It offers a noise floor of -144 dBm/Hz and a maximum output word rate of 8.832 MWords/s.

✓ Total Stock: 226,000 pcs

$ Price Range: $1.32

TEXAS Available from 1 distributor

✓ Authorised

✓ Non-Authorised

Distributor		Stock	Pricing	MOQ	PKG	Lead Time	Date Code	On Order Quantity	On Order Delivery
Romaks Technologies ✓ Non-Authorised Inventory information	226,000 pcs On Request	226000 pcs	On Request	1	On Request	On Request	On Request	On Request	On Request

TEXAS Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	New Products
Manufacturer Name	Texas Instruments
Input Capacitance	30 pF
Input Impedance	2.8 kΩ
Input Signal	9.6 Vp-p
Noise Floor	-144 dBm/Hz
Power Dissipation	570 mW
SVHC Present	Not Present

View Similar Products (0)

TEXAS Description

Short technical summary and product information.

The Texas Instruments AFE1302 is an Analog Front-End (AFE) integrated circuit designed to reduce the size and cost of ADSL-compliant systems. It provides the active analog circuitry necessary to interface an ADSL Digital Signal Processor (DSP) with external components like line drivers, receivers, filters, and transformers.

This IC is suitable for downstream data rates of 4Mbps and higher, operating at a clock rate of 35.328MHz. Key electrical specifications include a noise floor of -144 dBm/Hz and a maximum output word rate of 8.832 MWords/s with 16-bit resolution. The receive channel features a low-noise PGA and a delta-sigma Analog-to-Digital Converter (ADC), while the transmit channel includes a delta-sigma Digital-to-Analog Converter (DAC) and a programmable attenuator.

The AFE1302 operates on a single 5V supply, with digital circuitry supporting voltages from 3.3V to 5V. It consumes only 570mW of power. The device is housed in a TQFP-48 package, designed for surface mounting.

This AFE is intended for use with external amplifiers and filters to enhance noise reduction and dynamic range, making it a versatile component for ADSL applications.

TEXAS Quick Information

Product Type: Analog Front-End IC

Canonical Name: AFE1302 Analog Front-End

Subcategory: IC

TEXAS Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

TEXAS Estimated Pricing

Qty	Low	High
1+	$1.32	$1.32

Estimated market price range - modelled values for guidance only, not live distributor offers.

TEXAS Features

Low noise floor of -144 dBm/Hz.
High output word rate up to 8.832 MWords/s.
16-bit resolution for ADC and DAC.
Low power consumption of 570mW.
TQFP-48 package for surface mounting.

TEXAS Applications

Suitable for ADSL systems.
Interfaces DSP to line drivers.
Used with external filters and amplifiers.
Enables high downstream data rates.

TEXAS FAQs

7 frequently asked questions generated from this part’s specifications.

What package is this ADC available in?

TQFP-48.

What is the noise floor of the ADC?

-144 dBm/Hz typical.

What is the maximum sampling rate?

35.328 MHz.

What is the resolution?

16 bits (configurable as 15+1 or 14+2 sign bits).

What is the typical power dissipation?

570 mW.

Does the ADC include a programmable gain amplifier?

Yes, with a range of -6 dB to 40 dB.

What is the input impedance?

2.8 kΩ typical (pin-to-AVDD).
