The TEP 200WIRCM Series from Traco Power offers high-performance, isolated DC/DC converters designed for demanding applications. This specific model, TEP 200-4818WIRCM, provides a 48V output with a maximum current of 4.5A, delivering 216W of power.
Key electrical specifications include an efficiency of up to 91% and an isolation voltage of 3 kV. The converter supports ultra-wide 4:1 input voltage ranges, making it suitable for battery-operated systems. It operates reliably within an ambient temperature range of -40°C to 75°C.
Designed for industrial and railway environments, this converter features a robust chassis mount with a screw terminal block for secure connections. Its enclosed type construction offers protection in harsh conditions. The dimensions are 85.1mm in length, 61.0mm in width, and 33.8mm in height.
Compliance includes RoHS3, REACH Unaffected, and an MSL rating of 1. Approval agencies include CB, CE, and cURus, indicating its suitability for various international markets.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The TEP 200-4818WIRCM has an adjustable output voltage of +10 / -20% and a nominal output voltage of 48 VDC.
The maximum output current for the TEP 200-4818WIRCM is 4.5A.
This DC DC converter has a power rating of 216W.
The efficiency of the TEP 200-4818WIRCM is typically 90%, with a maximum of up to 91%.
The operating temperature range for the TEP 200-4818WIRCM is -40°C to 75°C.
The dimensions are 85.1mm in length, 61.0mm in width, and 33.8mm in height.
The TEP 200-4818WIRCM is approved by CB, CE, and cURus.
