The TEN 20-2422WI is a 20-watt isolated DC/DC converter module from Traco Power, part of the TEN 20WI series. It features an ultra-wide 4:1 input voltage range of 9 to 36 VDC (nominal 24 V) and provides dual regulated outputs of ±12 VDC, each capable of delivering 835 mA. The module achieves a typical efficiency of 81% and offers a voltage set accuracy of ±2% with output voltage adjustment of ±10%.
Designed for industrial and commercial ITE applications, the converter includes comprehensive protection features such as short circuit protection (indefinite with automatic recovery), over load protection at 150% of rated output, and over voltage protection. It also supports remote On/Off control. The input filter meets EN 55022 class A and FCC part 15 level A EMC standards without external components.
The TEN 20-2422WI is housed in a shielded metal case with an insulated baseplate, in a standard 7-DIP through-hole package measuring 50.8 x 40.6 x 10.2 mm. It operates over a temperature range of -40°C to +85°C with derating. I/O isolation is rated at 1500 VDC. The module is RoHS compliant and carries a 3-year product warranty.
| Qty | Low | High |
|---|---|---|
| 1+ | $93.07 | $93.07 |
| 10+ | $84.07 | $84.07 |
| 25+ | $82.27 | $82.27 |
| 50+ | $80.93 | $80.93 |
| 100+ | $79.60 | $79.60 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
9 to 36 VDC (nominal 24 V).
7-DIP through-hole module.
-40°C to +85°C with derating.
Yes, it is listed as RoHS3 compliant (lead-free design).
1500 VDC.
81%.
835 mA per output.
