| Category | |
| Manufacturer Name | |
| Applications | |
| Approval Agency | |
| Cord Length | |
| Current | |
| Efficiency | |
| Form | |
| Height | |
| Input Connector | |
| Input Type | |
| Input Voltage | |
| Length | |
| No Load Power Consumption | |
| Operating Temperature | |
| Output Connector | |
| Output Current | |
| Output Voltage | |
| Polarization | |
| Power (Watts) | |
| Region Utilized | |
| Voltage | |
| Width |
The TE90A1803Q01 from SL Power Electronics is a versatile AC/DC desktop power adapter designed for commercial ITE applications. This unit delivers a stable 18V DC output at a maximum current of 5A, providing a total power of 90W. It operates efficiently, meeting Level VI and CoC Tier 2 standards, with a low no-load power consumption of 150mW maximum.
The adapter accepts a wide input voltage range of 90 to 264 VAC and features an IEC 320-C18 input connector, with the power cord sold separately. The output is delivered via a standard barrel plug (2.5mm I.D. x 5.5mm O.D. x 9.5mm) with positive center polarization. Its compact desktop form factor (Class II) measures 153.0mm x 68.0mm x 34.5mm, making it suitable for various installations. The operating temperature range is from -20°C to 70°C, ensuring reliable performance in diverse environments. This adapter is CE approved for international use.
90 to 264 VAC.
18 Vdc at 5 A.
-20°C to 70°C.
Desktop (Class II).
153.0mm x 68.0mm x 34.5mm.
Level VI and CoC Tier 2.
Barrel plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm.
