| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
2,744 pcs
|
2744 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Angle of Half Intensity | |
| Color | |
| Common Pin | |
| Current | |
| DC Forward Current | |
| Digit | |
| Digit Height | |
| Display Type | |
| Forward Voltage (Minimum/Typical/Maximum @ If=20 mA) | |
| Lead Spacing | |
| Luminous Intensity | |
| Millicandela Rating | |
| Number of Characters | |
| Operating Temperature | |
| Peak Forward Current | |
| Power Dissipation | |
| Power Dissipation (Max) | |
| Reverse Voltage | |
| Soldering Temperature | |
| Storage Temperature | |
| Voltage | |
| Wavelength |
The Vishay Dale TDCR1050M is a four-digit, 0.39-inch (10.00mm) 7-segment clock display with an active colon between the second and third digits. It utilizes high-efficiency AlInGaP technology, offering white segments on a dark surface for clear visibility. This display is designed for applications requiring a recommended viewing distance of up to 7 meters.
Key electrical characteristics include a typical forward voltage of 2.4V at 20mA, a typical luminous intensity of 4000 mcd at 10mA, and a wavelength of 631nm. The maximum power dissipation is rated at 60mW. The display operates within a temperature range of -40°C to +85°C and has a storage temperature range of -40°C to +100°C.
Packaged in a 16-DIP format, the TDCR1050M is suitable for through-hole mounting. It is designed as a common anode display, with individual segments rated for a maximum reverse voltage of 5V and a DC forward current of 25mA. The peak forward current is 160mA with a 1/10 duty cycle at 1kHz. The angle of half intensity is ±50°.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The digit size is 0.39 inches (10.00mm).
The display is red.
The typical forward voltage is 2.4V at 20mA.
The typical luminous intensity is 4000 mcd at 10mA.
The wavelength is 631nm.
The maximum power dissipation is 60mW.
The operating temperature range is -40°C to +85°C.
