| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
95 pcs
|
95 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| AEC Qualified | |
| Automotive Grade | |
| Industrial Grade | |
| Medical Grade | |
| Military Grade | |
| Output Current | |
| Storage Temperature | |
| Tape & Reel |
The TDA2006 is a monolithic integrated circuit from Thomson-CSF, designed for use as a low-frequency class AB amplifier. It is housed in a Pentawatt package.
This audio amplifier IC provides significant output power, delivering typically 12W into a 4Ω load and 8W into an 8Ω load at ±12V supply voltage with 10% distortion. The TDA2006 is known for its high output current capability and very low harmonic and cross-over distortion.
Key features include an integrated short circuit protection system that automatically limits dissipated power to keep output transistors within their safe operating area, along with a conventional thermal shutdown system. The TDA2006 is pin-to-pin equivalent to the TDA2030, offering a convenient upgrade path or alternative.
Applications for the TDA2006 include various audio amplification systems where reliable power output and low distortion are required. Its robust protection features make it suitable for demanding environments.
| Qty | Low | High |
|---|---|---|
| 1+ | $1.92 | $1.92 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The TDA2006 typically provides 12W output power on a 4Ω load and 8W on an 8Ω load at ±12V.
The TDA2006 is intended for use as a class AB amplifier.
The TDA2006 is available in the Pentawatt package.
The RoHS status is RoHS3 Compliant.
The Moisture Sensitivity Level (MSL) is 1 Unlimited.
