TDA1051 The TDA1051 is an AF Power Amplifier integrated circuit from SESCOCEM. It offers high gain and a DC output voltage stabilizer.
Mfr Part #:

TDA1051

Available from 1 distributors
Mfr Name: SESCOCEM
SESCOCEM
The TDA1051 is an AF Power Amplifier integrated circuit from SESCOCEM. It offers high gain and a DC output voltage stabilizer.
✓ Total Stock: 30 pcs
$ Price Range: $1.94

TDA1051 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Partservice ✓
Non-Authorised Inventory information
30 pcs
On Request
30 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

TDA1051 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Dimensions
Mounting Type
Operating Temperature
Package / Case
Storage Temperature
Tape & Reel
Voltage
Weight
View Similar Products (0)

TDA1051 Description

Short technical summary and product information.

The TDA1051 is an integrated circuit designed as an AF Power Amplifier. Manufactured by SESCOCEM, this component features high gain, a differential preamplifier, and an input double emitter follower.



Key electrical specifications include a nominal supply voltage (Vcc) of 12V and a quiescent current (Icc) of 50mA. The output current (Iout) can reach up to 1A, with a nominal output power (Pout) of 1W into a 15Ω load. Input resistance (R in) is 50 kΩ, and distortion (Dist.) is rated at 0.3% at 150mW.



The device operates within a storage temperature range of -25°C to +125°C and has a power dissipation (Ptot) of 600mW. It is housed in a QIP-14 package, suitable for through-hole mounting.



Additional features include a DC output voltage stabilizer. The dimensions of the package including pins are 18 x 7 x 8 mm, with a weight of 1g.

TDA1051 Quick Information

Product Type: Integrated Circuit
Canonical Name: TDA1051 AF Power Amplifier Integrated Circuit
Subcategory: Special Purpose Transistor

TDA1051 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

TDA1051 Estimated Pricing

Qty Low High
1+ $1.94 $1.94

Estimated market price range - modelled values for guidance only, not live distributor offers.

TDA1051 Features

  • High gain AF power amplifier IC.
  • 12V nominal supply voltage.
  • 1A maximum output current.
  • 1W nominal output power.
  • QIP-14 through-hole package.

TDA1051 Applications

  • Suitable for high-gain differential preamplifiers.
  • Used in DC voltage stabilization circuits.
  • Ideal for audio power amplification at 12 V.
  • Applicable in thermal temperature range -25 to 125°C.
  • Designed for low power dissipation applications.

TDA1051 FAQs

4 frequently asked questions generated from this part’s specifications.
What is the operating voltage for the TDA1051?

The nominal supply voltage (Vcc) for the TDA1051 is 12V.

What is the output power of the TDA1051?

The TDA1051 has a nominal output power of 1W at a 15Ω load.

What is the package type for the TDA1051?

The TDA1051 is supplied in a QIP-14 package.

What is the operating temperature range for the TDA1051?

The TDA1051 can be stored within a temperature range of -25°C to +125°C.
